Adaptive Ducted Air Conditioning - Ducted Air conditioning unit
Verified by manufacturer over a year ago
R32 Compact Model - 5.7kW Indoor Unit S - 6071PF3E
R32 Compact Model - 5.7kW Indoor Unit S - 6071PF3E
Slim and Flexible Adaptive Ducted Air conditioning unit.
Application
A ducted system that delivers air through ducting pipes into the rooms via vents on floors walls and ceilings. Suitably use for residential and commercial application. Perfectly suited for installation with low ceiling heights or alternately vertical installation.
Description
A high static pressure adaptive ducted air conditioning unit with slim, flexible design and exceptional performance. A ducted system consisting of an outdoor unit and concealed indoor unit and delivers air through ducting pipes. Some of its significant features include:
- Flexible and easy to install.
- Auto fan operation.
- Quiet operations.
- Automatic restart function.
- Dry mode.
- Self-diagnosing function.
- Intuitive voice control.
- High energy efficiency.
- Blue fin technology anti-corrosion fetaure.
Design with 24-hour Nanoe™ X air purification that can run independently from cooling or heating mode.
Product benefit:
- Active deodorisation.
- Inhibition of hazardous substances.
- Inhibition of mould, bacteria and viruses.
- Inhibition of pollen and of major allergens.
- Mouisturises and hydrates.
Can be controlled with wired remote controller that offers integration and connects directly to a variety of Cloud base apps.
General information
Color | White |
Finish | Smooth |
Size | Manufacturer guidanceSmall Chassis: 6.8 kW Large Chassis : 9.5 - 13.4 kW |
Length | 730 mm Guidance for specification option: Small Chassis: Indoor 730mm Large Chassis: Indoor 730mm 340 mm Guidance for specification option: Small Chassis: Outdoor 340mm Large Chassis: Outdoor 340mm Manufacturer guidanceSmall Chassis: Indoor 730 mm. Outdoor 340 mm. Large Chassis: Indoor 730 mm. Outdoor 340 mm. |
Width | 1000 mm 940 mm 1400 mm Manufacturer guidanceSmall Chassis: Indoor 1000 mm. Outdoor 940 mm. Large Chassis: Indoor 1400 mm. Outdoor 940 mm. |
Height | 250 mm 996 mm 1416 mm Manufacturer guidanceSmall Chassis: Indoor 250 mm. Outdoor 996 mm. Large Chassis: Indoor 250 mm. Outdoor 1416 mm. |
Warranty description | Five year |
Uniclass | |
NATSPEC National Classification System | 0722 Room Air Conditioners 0721 Packaged Air Conditioning 0702 Mechanical Design and Install |
SpecPack | 15782 Air Conditioning - Packaged Units |
SpeedSpec | 15738 Domestic Air-Conditioning |
Specification data - Room air conditioning systems
System performance | 6.8 - 13.4 kW. |
Air ductwork and accessories | |
Ductwork | Flexible ductworkManufacturer guidanceMaximum duct length is.. |
Description | Panasonic ducted air conditioning system concealed indoor unit design with powerful airflow. |
Dimensions | 250 H X 1000 W X 730 D mm. |
TotalCoolingCapacity | 6.8 - 13.4 kW. |
HeatingCapacity | 7.5 - 15.5 kW. |
Power input | 240V (1-Phase). |
Power supply | AC. |
Acoustic performance | 51 dBA. |
Volume | 1018 L/s. Guidance for specification option: Air volume. |
Length | 5 - 50 m. |
RefrigerantClass | R 32. |
PipeConnection | 9.52 - 15.88 mm. |
Controller | Remote included. |
Size (w x h x d) | 86 x 86 x 25 mm. |
PowerSource | 240 V (1 Phase). |
Operating temperature range | -15°C - 46°C. |
Sustainability data
Country of material origin | Malaysia |
Country of product manufacture | Malaysia |
