AGS 50 series awning casement window

Name: AGS 50 series awning casement window
Brand: Capral Aluminium
SKU: bmJXvkjGd88DVrLgoysLC4

Verified by manufacturer 5 months ago

Capral Aluminium

Third party certifications:

Declare
Certificate type

The Artisan Architectural 50 Series window is a high performance commercial window that is capable of being installed as either an operable awning or casement sash.

Jump to:

+61 7 3816 7500 Website

Application

Residential and commercial applications.

Description

The Artisan Architectural 50 Series window is a high performance commercial window that is capable of being installed as either an operable awning or casement sash.

The Artisan Architectural 50 Series window may be fabricated into a number of different frame types allowing for a wide variety of applications. For enhanced thermal comfort and performance, both thick and double glazing is available supporting insulated glass units up to 38mm thick.

General information

Finish	Powder coated or anodised.
Material	Aluminium.
Shape	- Manufacturer guidance Various profiles available.
Size	Various sizes available. Maximum Recommended Sizes Sash Height A & H - 1800mm, C & J - 1500mm Sash Width A & H - 1500mm, C - 900, J - 700.

Uniclass	Pr_30_59_98_02 Aluminium window unitsPrimary
NATSPEC National Classification System	0451a Windows and Glazed Doors – Metal 0451 Windows and Glazed Doors
SpeedSpec	08520 Metal Windows and Glazed Doors
SpecPack	08520 Metal Windows and Glazed Doors

Specification data - Aluminium window units

Operation:	Manual. Automated.
Configurations	Awning on Stays. Awning on Hinge Head. Casement on Stays. Casement on Hinge Section. Jockey Sash.
Sash (h x w)	Awning Sash: 1.8m Height or 1.5m Width and 60kgs Weight. Jockey Sash: 1.5m Height or 0.7m Width and 15kgs Weight.
Frame dimensions	Awning Stay Sash (A) - 51 x 65mm / Awning Hinge Sash (H) - 51 x 50.5 & 65mm / Casement Sash (C ) - 51 x 65mm / Jockey Sash (J) - 18 & 24 x 40mm.
Glazing	Single. Double. Triple.
Performance:	Awning Max SLS: 1750pa ULS: 3750pa WATER: 1000pa / Casement Max SLS: 1500pa ULS: 2700pa WATER: 600pa.
Standard	AS2047.
Acoustics	Max Rw 40 (-1C;-4Ctr).
Cyclonic impact testing	No
Bushfire attack level (BAL)	up to BAL29 DTS.
Hardware	• Aluminium Stays. • Stainless Steel Stays. • Restrictor. • Chain Winder. • Twin Chain Winder. • Automated Chain Winder. • Cam Handles.
Integral accessories	• Flyscreen. • Bushfire Screen. • Security Screen.
