Altro Orchestra™ Custom

Verified by manufacturer over a year ago

Altro Flooring

Custom floors designed exactly to suit every space. 15dB impact sound reduction and comfort underfoot with excellent resistance to residual indentation.

Jump to:
03 9764 7000 Website

Application

Altro Orchestra Custom is suitable application for areas where comfort and sound reduction are important:

  • Restaurants, cafés and bars.
  • Public areas, entrances and sensory rooms in primary, secondary and tertiary education.
  • Retail, offices and commercial building spaces where looks count.
  • Reception, changing rooms and food concessions in sports centres and gyms.


Works well with:

  • Altro Pisces.
  • Altro Aquarius.
  • Altro Walkway 20.
  • Altro Fortis Titanium.
  • Altro Whiterock White.
  • Altro Whiterock Satins.
  • Altro Whiterock Chameleon.
  • Altro Whiterock Digiclad (custom).
  • Altro Cantata.
  • Altro Orchestra.
  • Altro Wood
  • Altro Wood Comfort
  • Altro Wood adhesive-free.

Description

Customise to suit every space for areas where looks not only count, but can positively affect the wellbeing of the people who live, work or visit.

Altro Orchestra Custom is possible to create a totally unique space, completely tailored to how the area will be used, and who is using it. Some of its significant features include:

  • Ease of maintenance.
  • Slip resistant.
  • Sustainable PVC flooring.

General information

Color

-

Manufacturer guidance

Available in wide range of colours. Consult manufacturer for details.

Finish

Slip-resistant.

Material

PVC.

Length

20000 mm

Manufacturer guidance

Roll size. Contact manufacturer for details.

Width

2000 mm

Warranty description

Ten years.

Manufacturer guidance

Claims against warranty for colour, batch or obvious material

defects will only be considered if the flooring has not yet

been permanently bonded.

Uniclass

Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary

NATSPEC National Classification System

0651 Resilient Finishes

SpecPack

09650 Resilient Flooring

SpeedSpec

09650 Resilient Flooring

Specification data - Polyvinyl chloride (PVC) sheets

Standard

To EN 651 for heterogeneous PVC sheet.

Use class

To ISO 10874, Class 34 and 42.

Material

Heterogeneous PVC.

Backing layer

Felt backed.

Width

2000 mm.

Thickness

2.85 mm.

Manufacturer guidance

To EN ISO 24346.

Colour and pattern

Cobbles 1.

Grass 1.

Grass 2.

Grass 3.

Grass 4.

Gravel 1.

Gravel 2.

Hexagon Border Grey 1.

Hexagon Border Monotone 1.

Hexagon Border Pastel 1.

Hexagon Border Sand 1.

Hexagon Border Wood 1.

Hexagon Cube Blue 1.

Hexagon Cube Grey 1.

Hexagon Cube Monotone 1.

Hexagon Cube Orange 1.

Hexagon Cube Wood 1.

Hexagon Cube Wood 2.

Hexagon Flower Coral 1.

Hexagon Flower Monotone 1.

Hexagon Flower Orange 1.

Hexagon Flower Stone 1.

Hexagon Flower Wood 1.

Hexagon Parquet Black and White 1.

Hexagon Parquet Gold 1.

Hexagon Parquet Orange 1.

Hexagon Parquet Rose 1.

Hexagon Parquet Wood 1.

Hexagon Triangle Grey 1.

Interlocked Cube Black 1.

Interlocked Cube Blue 1.

Interlocked Cube Blue 2.

Interlocked Cube Brass 1.

Interlocked Cube Gold 1.

Interlocked Cube Gold 2.

Interlocked Cube Green 1.

Interlocked Cube Silver 1.

Interlocked Cube Wood 1.

Interlocked Cube Yellow 1.

Leaves 1.

Leaves 2.

Moss 1.

Moss 2.

Paving 1.

Paving 2.

Pebbles 1.

Sand 1.

Sand 2.

Water 1.

Water 2.

Slip resistance

-

Standard

To AS/NZS 4586.

Slip resistance value

Low.

Guidance for specification option:

≥ 0.30 / DS as per EN 13893.

R10 as per DIN 51130.

Oil wet inclining platform test

R10.

Fire performance

-

Standard

To EN ISO 9239-1, EN ISO 11925-2 and EN 13501-1.

Group number

-

Manufacturer guidance

Pass - ≥ 4.5 kW/m².

Critical radiant flux

Cfₗ-s1.

Smoke development rate

185 %.

Acoustic performance

-

Standard

To EN ISO 10140-3.

Value

15 dB.

Recycled content

-

Standard

None.

Value

0.

Delivery and storage

Delivered from Melbourne if in stock, if not in stock from the UK.

Dimensions

20 000 l x 2000 w (mm).

Guidance for specification option:

Roll size.

Manufacturer guidance

 To EN ISO 24341.

Wear layer thickness

0.7 mm.

Manufacturer guidance

To EN ISO 24340.

Flexibility (to EN-ISO 24344)

Pass.

Abrasion resistance

Yes, type W.

Guidance for specification option:

Castor chair abrasion.

Manufacturer guidance

To EN 425.

Wear resistance

Group T.

Guidance for specification option:

 To EN 660-2.

Light fastness to EN-ISO 105-B02

≥ 6.

Chemical resistance (to EN-ISO 26987)

Good.

VOC emissions

Approved.

Guidance for specification option:

CDPH 1350 / Floorscore Indoor Air Comfort Gold.

Certification

Eurofins Indoor Air Comfort (Gold) certified.

Emission class M1 certified.

FloorScore certified.

†A+ BRE rated.

Guidance for specification option:

To EN 15804:2012 + A1:2013 and BRE Global Scheme Document SD207.

O-phthalate - free.

Show more

Sustainability data

Country of product manufacture

Germany
