HPL Collection - Coloured Core Laminate

Verified by manufacturer over a year ago

Abet Laminati

Compact or solid grade high-pressure laminate (HPL) boards.

Jump to:
+61 2 9672 7300 Website

Application

Suitable for internal use on a wide range of applications.

Description

  • PRINT HPL is a high-pressure decorative laminate, in other words a panel consisting of layers of cellulose fibers that are impregnated with thermosetting resins and subjected to a high pressure process consisting in the simultaneous application of heat and pressure. This causes at the same time the fluidization and polycondensation of the resins, resulting in a homogeneous, non-porous material with the required surface finish.
  • The materials referred to are high pressure decorative laminates (HPL) according to the European norm EN 438 and to ISO 4586.
  • PRINT HPL are sheets consisting of layers of cellulose fibrous material (normally paper) impregnated with thermosetting resins and bonded together by the high pressure process. The process, defined as the simultaneous application of heat (≥ 120° C) and high specific pressure (≥ 5 MPa) provides flowing and subsequent curing of the thermosetting resins to obtain a homogenous non-porous material (≥ 1,35 g/cm³) with the required surface finish.

General information

Color

Beige

Black

White

Finish

Sei.

Material

HPL.

Shape

Rectangle

Uniclass

Pr_25_71_63_15 Compact or solid grade high-pressure laminate (HPL) boardsPrimary

NATSPEC National Classification System

0551a Joinery – Manufactured Casework

0551 Joinery

0571 Workstations

0572 Miscellaneous Furniture

SpeedSpec

12720 Workstations

12300 Manufactured Casework

06400 Joinery

SpecPack

06400 Joinery

11460 Unit Kitchens

12720 Workstations

12300 Manufactured Casework

Specification data - Compact or solid grade high-pressure laminate (HPL) boards

Classification

-

Material type

HPL.

Fire hazard properties

-

Flammability index

-

Manufacturer guidance

PRINT HPL are not considered to be flammable. They will burn only in a fire situation, in presence of open flames. Refer to manufacturer's product data sheet.

Thickness

1 mm.

1.2 mm.

1.5 mm.

2 mm.

3 mm.

4 mm.

6 mm.

8 mm.

10 mm.

12 mm.

14 mm.

Panel size

-

Length

3050 mm.

Width

1300 mm.

Finish

Sei.

Guidance for specification option:

The historical Abet Laminati finish designed in the Sixties – matte and pleasant to the touch – became the classic and universal finish of laminate.

Colour

405 Bianco Porcellana.

410 Bianco Ghiaccio.

421 Nero.

Delivery and storage

-

Manufacturer guidance

  • Storage and transportation should be carried out in accordance with the General Processing Recommendations for PRINT HPL; no special precautions need to be taken.
  • For transportation, PRINT HPL are classified as a non hazardous product; no labelling is required.
  • Refer to manufacturer's product data sheet.

Sustainability data

Contains Red List materials

No

Manufacturer guidance

Decorative laminates are cured and therefore chemically inert. Gas release from surfaces and edges are insignificant. Due to their very low permeability PRINT HPL bonded to wood based substrates act as a barrier against possible formaldehyde emissions coming from the substrates. PRINT HPL formaldehyde emission level is far below the limit for wood based materials. There is no migration affecting foodstuffs and, consequently, PRINT HPL are approved for contact with foodstuffs.

Refer to manufacturer's product data sheet.

Country of material origin

Italy

Country of product manufacture

Italy

Recyclability

-

Manufacturer guidance

  • On account of their high calorific value (18 - 20 MJ/kg)* PRINT HPL are ideal for thermal recycling. When burned completely at 850 °C, PRINT HPL produce water, carbon dioxide and oxides of nitrogen. Therefore PRINT HPL comply e.g. with the Kreislaufwirtschaftsgesetz (para. 6). Well controlled burning processes are achieved in modern, officially approved industrial incinerators. Ashes of this process can be brought to controlled waste disposal sites.
  • The CER code for the disposal of the laminate and the dust of laminate is 030105.
  • Refer to manufacturer's product data sheet.

Literature

HPL Test Report and Group Number Classification

HPL Test Report and Group Number Classification
