Invisi-Gard
Verified by manufacturer over a year ago
Invisi-Gard stainless steel security screen comprising a 316 marine grade stainless steel mesh.
Application
Fits to a heavy duty extruded aluminium perimeter frame, custom made to suit any product and application.
Description
Invisi-Gard stainless steel security screen comprising a 316 marine grade stainless steel mesh.
Features and benefits:
- Stainless steel mesh is a high tensile woven mesh providing strong, corrosion resistant product, powder coated in a very tightly controlled, chrome free environment.
- Multi-point locking in hinged and sliding doors.
- Grip protection.
- Fitting Invisi-Gard® security screens over the outside of a window can improve the energy efficiency by up to 51%.
- 15-year warranty.
Application:
Fits to a heavy duty extruded aluminium perimeter frame, custom made to suit any product and application.
General information
Finish | Black |
Material | Stainless steel Guidance for specification option: 316 stainless steel grade mesh. |
Shape | Rectangle Square |
Warranty description | 15 years. |
Uniclass | |
NATSPEC National Classification System | 0451d Windows and Glazed Doors – Window and Door Security 0451a Windows and Glazed Doors – Metal 0451 Windows and Glazed Doors |
SpecPack | 08660 Window and Door Security 08200 Doors, Door Frames and Hatches |
SpeedSpec | 08660 Window and Door Security 08200 Doors and Door Frames |
Specification data - High-security doorsets
Product Reference | Invisi-Gard. |
Thickness | 0.8 mm. 1.2 mm. |
Aperture size | 1.6 x 1.6 mm. Guidance for specification option: To mesh design to resist 250 N outward force (to AS 5203). |
Ventilation | 44%. Guidance for specification option: Open Area when used for a louvre or screen. |
Hardware | Multi-point locking. Guidance for specification option: Options vary loading - refer to manufacturer's technical manual. |
Fire attenuation | 55% at 40 kW/m². Guidance for specification option: Achieves a fire attenuation rating (to AS 1530.4-2014 APPENDIX B7). |
