Plus 60 Fire Barrier
Verified by manufacturer over a year ago
Flexible fire barrier used as a fire engineered solution to continue compartment walls up into the roof void.
Application
TBA Firefly™ Plus 60 Fire Barrier is easy to install flexible fire barrier is used as a fire engineered solution to continue compartment walls up into the roof void, maintaining both the integrity and insulation of the compartmentation between dwellings, lift shafts and stairwells, ideal for but not limited to strata units.
Can also be used to provide inside out / outside in fire protection to boundary walls on both steel and timber framed buildings. The flexibility and fire rating level makes this product perfect for bespoke applications.
Description
TBA Firefly™ Plus 60 Cavity Fire Barrier is a flexible and lightweight fabric with an inner core of insulating fire protection.
Also available with a fire rated silicone coating - Product Code FLYPLUS60RS
General information
Color | White |
Finish | Flexible. |
Material | Fabric. Guidance for specification option: With an inner core of insulating fire protection. |
Length | 6000 mm |
Width | 1300 mm |
Uniclass | |
NATSPEC National Classification System | 0182 Fire-Stopping |
SpecPack | 07810 Fireproofing |
SpeedSpec | 07810 Fireproofing |
Specification data - Vertical active fire curtain barriers
Performance | |
Fire resistance level | |
Standard | To AS 1530.4- 2005.To AS 4072.1-2005.Manufacturer guidanceExova Warringtonfire Report No: 22766. |
Value | 30/30/30.-/60/30. |
Fire hazard properties | |
Standard | To AS/NZS 1530.3. |
Group number | 3. |
Dimensions | 6000 l x 1300 w (mm). |
Acoustic performance | 46 dB. |
Fabric thickness | 10 mm. Guidance for specification option: 2.2 kg per m². |
Certification | CSIRO certified. AWTA certified. Guidance for specification option: AS 1530.3 Simultaneous Determination of Ignitability, Flame Propagation, Heat Release and Smoke Release. Exova Warringtonfire certified. |
Fire testing - non combustibility | To AS 1530.1. Guidance for specification option: CSIRO Report No: FNC11220. |
Support height | 3000 mm. Guidance for specification option: Height between vertical support of barrier. |
