ThermAFrame Flush Glazed Thermally Broken Framing

Verified by manufacturer over a year ago

Alspec

A high performance energy efficient frame for use on high rise building envelopes and shopfront applications.

Jump to:
+61 2 9834 9500 Website

Application

For use on high rise building envelopes and shopfront applications for internal and external use.

Description

ThermAFrame flush glazed thermally broken framing is a high performance energy efficient frame for use on high rise building envelopes and shopfront applications. Some of its features include:

  • Utilises energy performance to meet project requirements, achieving Uw values down as low as 1.9 W/m2K.
  • Pocket design to framing allows for insertion of optional accessories to reduce total window Uw values where required.
  • 101.6 mm and 150 mm x 60 mm Framing System.
  • 38 mm wide glazing pocket accepts double glazed options up to 32 mm.
  • Thermally broken sub framing designed to support heavy double glazed frames including the option of a two piece sub jamb for easier installation.
  • Thermally broken hinge door threshold also available.
  • The glazing pocket are designed to allow for the installation of large Insulated glass units (IGUs) and provides the required glass cover to comply with AS 1288.
  • Available as internally or externally glazed.

General information

Material

Aluminium.

Width

101.6 mm

150 mm

Height

60 mm

Uniclass

Pr_30_59_99_02 Aluminium window wallsPrimary

NATSPEC National Classification System

0451a Windows and Glazed Doors – Metal

0451 Windows and Glazed Doors

SpeedSpec

08520 Metal Windows and Glazed Doors

SpecPack

08520 Metal Windows and Glazed Doors

08450 Fully Glazed Entrance Facades

Specification data - Aluminium window walls

Glazing or infill

-

Standard

To AS 1288.

Product Reference

ThermAFrame Flush Glazed Thermally Broken Framing 101.6 x 60 mm.

Guidance for specification option:

To AS 1288.

ThermAFrame Flush Glazed Thermally Broken Framing 150 x 60 mm.

Guidance for specification option:

To AS 1288.

Configuration

A range of configurations is available, consult manufacturer for information and insert requirements.

Glass position

Front.

Threshold

Thermally broken hinge door threshold.
