Wonderglas - GC - Skylight roofing and cladding
Verified by manufacturer over a year ago
Wonderglas GC (GC = Gel Coated Surface) is a UV protected GRP (Glass reinforced polyester) sheeting product.
Application
Used within a wide range of applications.
Description
UV protected glass reinforced polyester (GRP) sheeting with a gel coated surface which has been chemically cross bonded to the sheet. Some of its features include:
- Hail Resistance
- Stable Light Transmission
- UV Stable 100 Micron Gel Coating
- Cuts 99% of UV Transmission
- Low Surface Erosion
- Chemical Resistance
General information
Color | Clear Other Manufacturer guidanceAvailable in Ice-Clear, Opal, Cool-lite. |
Finish | Coated |
Material | Fiber-glass |
Shape | Trapezoid Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 25 year |
Uniclass | |
NATSPEC National Classification System | 0431 Cladding - Combined 0429 Roofing - Glazed 0421 Roofing - Combined |
SpecPack | 08900 Glazed Curtain Walls 08620 Skylights |
SpeedSpec | 08620 Skylights 07610 Roofing and Roof Plumbing 07462 Cladding External Walls |
Specification data - Glass-reinforced plastics (GRP) profiled sheets
Standard | To AS 4256.3.Guidance for specification option: The product must be installed strictly in accordance with AS1562.3 Design and installation of sheet roofing and wall cladding Part 3: Plastic, and with the Manufacturer’s recommendations and specifications |
Classification | |
Grade | 2.4 kg/m³.3.05 kg/m³. |
Profile | 406 Decking.Guidance for specification option: 406 mm cover. 1º minimum pitch. 450 Decking.Guidance for specification option: 450 mm cover. 1º minimum pitch. 5 Rib.Guidance for specification option: 760 mm cover. 2º minimum pitch. 500 Decking.Guidance for specification option: 500 mm cover. 1º minimum pitch. 650 Prodek.Guidance for specification option: 650 mm cover. 2º minimum pitch. Alcan LT7.Guidance for specification option: 890 mm cover. 3º minimum pitch. Corrugated.Guidance for specification option: 760 mm cover. 5º minimum pitch. Hardies Super 61.Guidance for specification option: 003 mm cover. 5º minimum pitch. Klip-lok 700, Speed Deck Ultra.Guidance for specification option: 700 mm cover. 1º minimum pitch. Kliplok 406.Guidance for specification option: 406 mm cover. 1º minimum pitch. Long Span.Guidance for specification option: 700 mm cover. 3º minimum pitch. Spandek Hi-Ten.Guidance for specification option: 700 mm cover. 3º minimum pitch. |
Length | Can be made to order. |
Cover width | 450 mm.Guidance for specification option: 450 Decking 406 mm.Guidance for specification option: Kliplok 406 406 Decking 500 mm.Guidance for specification option: 500 Decking 650 mm.Guidance for specification option: 650 Prodek 700 mm.Guidance for specification option: Spandek Hi-ten Long span Klip-lok 700 Speed deck ultra 760 mm.Guidance for specification option: Corrugated Five rib 890 mm.Guidance for specification option: Alcan LT7 1003 mm.Guidance for specification option: Hardies super 6 |
Colour | Cool-Lite.Guidance for specification option: 38% light transmission, 23.5% heat transmission. Ice Clear.Guidance for specification option: 74% light transmission, 68% heat transmission. Opal.Guidance for specification option: 72% light transmission, 64% heat transmission. |
Accessories | FS Firecheck. Manufacturer guidanceConsult manufacturer for details. |
Sustainability data
Country of material origin | Australia |
Country of product manufacture | Australia |
Recyclability | No |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
