Expanded Polystyrene Insulation

Verified by manufacturer over a year ago

Quik-Therm

Quik-Therm Multi Purpose Insulation (MPI) is a continuous rigid foam insulation consisting of closed cell Type I, Type 2 or Type 3 Expanded Polystyrene (EPS) layered on two sides.

Jump to:
+1 204 736 3012 Website

Application

  • Steel Framed Buildings
  • Tilt-Up Concrete
  • Residential

Description

In one product, Quik-Therm MPI meets air, vapour and radiant barrier requirements.

  • Excellent dimensional stability – flexible and durable.
  • Depending on thickness, Quik-Therm MPI can be bent to 90 degree angles. Does not easily crack, chip or break.
  • NO thermal drift, and its R-value will remain stable over its entire service life.
  • Quik-Therm MPI does not promote mildew and mold.
  • Contains no dyes, formaldehyde, or ozone depleting blowing agents.
  • Recyclable – Quik-Therm MPI may contain up to 15% recycled content.
  • Manufactured in a variety of thicknesses and densities. 4'x8' sheets and 4'x72'x1/2" thick rolls (288ft2)


Rugged. Durable. Semi-Flexible. Impermeable.

Achieves code compliance as an all-in-one air, vapour and radon barrier and continuous insulation system. 4×8 sheets. Thicknesses up to six inches. Compressive strengths up to 40 psi. Optional tongue and groove connections.


Cold climate tested

Quik-Therm Insulation Solutions Inc. has undertaken a program of full scale thermal performance testing to ASTM C1363-05 Standard Test Method for Thermal Performance of Building Materials and Envelope Assemblies. Temperature range: Outside -18C/Inside +21C with a 22 KPH wind/-31 wind chill.


General information

Material

Expanded polystyrene (EPS)

CMS

07 21 13 Board InsulationPrimary

Specification data - Board Insulation

Sustainability data

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

15 %

Literature

Air Barrier Testing

Air Barrier Testing

MPI Technical Brochure

MPI Technical Brochure

MPI Technical Data Sheet

MPI Technical Data Sheet
