Piazza - Steel Grating Carpark Wall Cladding
Piazza - Steel Grating Carpark Wall Cladding
Piazza - Steel Grating Carpark Wall Cladding

Verified 2 days ago

Lang+Fulton

Verified 2 days ago

Lang+Fulton

Verified 2 days ago

Lang+Fulton
Summary
A steel grating with a square aperture of 25, 44, 66 or 132 mm for cladding, security screens or green wall trellis.
Color
Grey, Beige, Black, Blue, Bronze, Brown, Copper, Gold, Green, Red, Silver, White, Other, Yellow
-
-
Finish
Galvanized, Powder-coated
-
-
Material
Steel
-
-
Shape
Rectangle
-
-
Length
Bespoke
-
-
Width
Bespoke
-
-
Height
Bespoke
-
-

Specification

Performance requirements
-
-
-
Recycled content
56%.
-
-
Panel
-
-
-
Top edge
-
-
-
Material
Carbon steel S235JR.
-
-
Shape
Rectangular.
-
-
Finish
Hot-dip galvanized., Hot-dip galvanized and polyester powder coated, RAL.
-
-
Dimensions
Manufacturer's standard.
-
-
Side edges
-
-
-
Material
Carbon steel S235JR.
-
-
Shape
Rectangular.
-
-
Finish
As Top edge.
-
-
Dimensions
Manufacturer's standard.
-
-
Bottom edge
-
-
-
Material
Carbon steel S235JR.
-
-
Shape
Rectangular.
-
-
Finish
As Top edge.
-
-
Horizontal rails
-
-
-
Material
Carbon steel S235JR.
-
-
Shape
Circular.
-
-
Finish
As Top edge.
-
-
Dimensions
Manufacturer's standard
-
-
Vertical bars
-
-
-
Material
Carbon steel S235JR.
-
-
Shape
Rectangular.
-
-
Finish
As Top edge.
-
-
Dimensions
25 x 2 mm.
-
-
Fixings
Through holes in the framing bar., Through plates welded behind the vertical flat bars., Through plates welded between the vertical flat bars., With clamping brackets.
-
-

Additional properties

Panel Type
Piazza-25.
-
-
Panel size
-
-
-
Aperture
25 x 25 mm.
-
-
Other requirements
Not required., Shaped to suit non-uniform openings., Rolled to a radius.
-
-
Framing
Framed top and bottom with flat bars.
-
-
Orientation
Vertical flat bars and horizontal circular rails.
-
-
Accessories
Not required., Secondary support steelwork.
-
-

Sustainability data

Contains Red List materials
No
-
-
Country of material origin
Europe
-
-
Country of product manufacture
United Kingdom
-
-
Material
Steel
-
-
Embodied carbon
1.42 kg CO₂ eq/kg
-
-
Recyclability
100%
-
-
Recycled content
56 %
-
-
