Summary
Acoustic suspended ceiling system with recessed visible grid and a tegular edge.
Acoustic suspended ceiling system with recessed visible grid and a tegular edge.
Acoustic suspended ceiling system with recessed visible grid and a tegular edge.
Product certifications
- ISO 14021:2016 bsi ISO 14001:2015
- ISO 14021:2016 bsi ISO 14001:2015
- ISO 14021:2016 bsi ISO 14001:2015
Color
Beige, Blue, Brown, Grey, Orange, Purple, White, Cream, Ivory, Other
Beige, Blue, Brown, Grey, Orange, Purple, White, Cream, Ivory, Other
Beige, Blue, Brown, Grey, Orange, Purple, White, Cream, Ivory, Other
Finish
Other
Other
Other
Material
Wood wool, Steel, Mineral wool
Wood wool, Steel, Mineral wool
Wood wool, Steel, Mineral wool
Shape
Square, Rectangle
Square, Rectangle
Square, Rectangle
Length
600 mm, 1200 mm
600 mm, 1200 mm
600 mm, 1200 mm
Width
600 mm
600 mm
600 mm
Height
25 mm, 35 mm
25 mm, 35 mm
25 mm, 35 mm
Warranty description
Ten year
Ten year
Ten year
Specification
Ceiling support
Connect™ T24 grid.
Connect™ T24 grid.
Connect™ T24 grid.
Ceiling units
Saga E A2.
Saga E A2.
Saga E A2.
System accessories
Not required., Connect™ clips., Connect™ connectors and splines., Connect™ fixing devices., Connect™ suspensions and brackets., Connect™ angle trim., Connect™ shadow line trim., Saga Acoustic insulation., TECH Slab MT 3.1 insulation., Other.
Not required., Connect™ clips., Connect™ connectors and splines., Connect™ fixing devices., Connect™ suspensions and brackets., Connect™ angle trim., Connect™ shadow line trim., Saga Acoustic insulation., TECH Slab MT 3.1 insulation., Other.
Not required., Connect™ clips., Connect™ connectors and splines., Connect™ fixing devices., Connect™ suspensions and brackets., Connect™ angle trim., Connect™ shadow line trim., Saga Acoustic insulation., TECH Slab MT 3.1 insulation., Other.
Additional properties
Installation
M574 - ceiling installation.
M703 - suspended ceiling.
M703C4 - suspended ceiling.
Surface texture
Elegant., Discreet., Normal.
Elegant., Discreet., Normal.
Elegant., Discreet., Normal.
Reaction to fire
To EN 13501-1, A2-s1,d0.
To EN 13501-1, A2-s1,d0.
To EN 13501-1, A2-s1,d0.
Size (length x width)
600 x 600 mm., 1200 x 600 mm.
600 x 600 mm., 1200 x 600 mm.
600 x 600 mm., 1200 x 600 mm.
Overall thickness
25 mm., 35 mm.
25 mm., 35 mm.
25 mm., 35 mm.
Edges
Wood wool tegular edges - natural., Wood wool tegular edges - painted.
Wood wool tegular edges - natural., Wood wool tegular edges - painted.
Wood wool tegular edges - natural., Wood wool tegular edges - painted.
Colour
Natural., White., Cement grey., Light grey., Dark grey., Glade., Lush., Sand., Mountain., Summer., Coastline., Lilac., Fog., Other.
Natural., White., Cement grey., Light grey., Dark grey., Glade., Lush., Sand., Mountain., Summer., Coastline., Lilac., Fog., Other.
Natural., White., Cement grey., Light grey., Dark grey., Glade., Lush., Sand., Mountain., Summer., Coastline., Lilac., Fog., Other.
Core material
Wood wool.
Wood wool.
Wood wool.
Constant humidity resistance
To EN 13964:2014, Class C, relative humidity 95% and 30°C.
To EN 13964:2014, Class C, relative humidity 95% and 30°C.
To EN 13964:2014, Class C, relative humidity 95% and 30°C.
Thermal conductivity (maximum)
To EN 12664, 0.1 W/m·K.
To EN 12664, 0.1 W/m·K.
To EN 12664, 0.1 W/m·K.
Indoor climate
Eurofins Indoor Air Comfort®: IAC Gold.
French VOC: A+.
Finnish M1.
French VOC: A+.
Finnish M1.
Eurofins Indoor Air Comfort®: IAC Gold.
French VOC: A+.
Finnish M1.
French VOC: A+.
Finnish M1.
Eurofins Indoor Air Comfort®: IAC Gold.
French VOC: A+.
Finnish M1.
French VOC: A+.
Finnish M1.
Standard
CE marked according to the European harmonized standard EN 13964:2014.
CE marked according to the European harmonized standard EN 13964:2014.
CE marked according to the European harmonized standard EN 13964:2014.
Sustainability data
Contains Red List materials
No
No
No
Country of material origin
Sweden
Sweden
Sweden
Country of product manufacture
Sweden
Sweden
Sweden
Material
Wood wool, Steel, Mineral wool
Wood wool, Steel, Mineral wool
Wood wool, Steel, Mineral wool
Expected Life
50 year
50 year
50 year
