GEC Anderson Data Sheet - Edge 10
Anderson, GEC Ltd
GEC ANDERSON® BACK EDGE (10)
GEC Anderson® back/side integral upstand edge (10). Height: 20 - 250mm.
Depth: 12 / 20 / 25mm.
Base Radius: 6 / 10 / 20mm.
Front faces are capped when visible.
GEC Anderson Data Sheet - DR166 (DG44)L Double Bowl With Drainer
Anderson, GEC Ltd
DR166 (DG44) Decimetric® 1600x600mm - double bowl, single drainer - commercial grade stainless steel sinktop. 40mm lipped front and side edges and 100x20mm rear upstand. Bowl size: 400x400x250mm deep complete with Ø38mm outlet and overflow fittings. Sound deadened and plastic protected. (EN 1.4301 grade stainless steel). LH drainer.
GEC Anderson Data Sheet - DR177 (DG55)R Double Bowl With Drainer
Anderson, GEC Ltd
DR177 (DG55) Decimetric® 1700x700mm - double bowl, single drainer - commercial grade stainless steel sinktop. 40mm lipped front and side edges and 100x20mm rear upstand. Bowl size: 500x500x300mm deep complete with Ø38mm outlet and overflow fittings. Sound deadened and plastic protected. (EN 1.4301 grade stainless steel). RH drainer.
GEC Anderson Data Sheet - StorTidy V111
Anderson, GEC Ltd
StorTidy V111
V111 stainless steel StorTidy set comprising: 3 No upper shelves (200mm wide) and 1 No intermediate shelf with guardrail (315mm wide).450mm long with 1 No low shelf (315mm wide).
GEC Anderson Data Sheet - DR186 (DG54)L Double Bowl With Drainer
Anderson, GEC Ltd
DR186 (DG54) Decimetric® 1800x600mm - double bowl, single drainer - commercial grade stainless steel sinktop. 40mm lipped front and side edges and 100x20mm rear upstand. Bowl size: 500x400x250mm deep complete with Ø38mm outlet and overflow fittings. Sound deadened and plastic protected. (EN 1.4301 grade stainless steel). LH drainer.
GEC Anderson Data Sheet - G13 Single Bowl
Anderson, GEC Ltd
Technical data sheet for GEC Anderson stainless steel single bowl: 150x330x150mm.
The bowl is complete with Ø38mm waste and overflow fittings.
Can be configured as required.
GEC Anderson Data Sheet - DR187 (DG55)L Double Bowl With Drainer
Anderson, GEC Ltd
DR187 (DG55) Decimetric® 1800x700mm - double bowl, single drainer - commercial grade stainless steel sinktop. 40mm lipped front and side edges and 100x20mm rear upstand. Bowl size: 500x500x300mm deep complete with Ø38mm outlet and overflow fittings. Sound deadened and plastic protected. (EN 1.4301 grade stainless steel). LH drainer.
GEC Anderson Data Sheet - Edge 7
Anderson, GEC Ltd
GEC ANDERSON® FRONT / SIDE EDGE (7) GEC Anderson® front/side turn-down edge (7). Standard height: 20mm (Option: 8 - 250mm). Standard lower return: 10mm (Option: 10 - 65mm). See also GEC Anderson® edge (6) and edge (8).
GEC Anderson Data Sheet - Series A sink: A70T
Anderson, GEC Ltd
The A70T is one of the GEC Anderson® Series A range of individual stainless steel sinks, including tap landing. Series A sinks are of the highest quality and finish and are available in single, double and combination sizes.
• Internal bowl size: 700x400x200mm with 15mm corner radius • 90mm tap landing with Ø35mm taphole
• 20 mm flat flange (Overall size: 740x510mm)
• Fixing options: Undermount / Inset / Flushmount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow fittings • Sound deadended and plastic protected
GEC Anderson Data Sheet - Separator V55
Anderson, GEC Ltd
Separator V55
V55 Stainless steel (EN 1.4401 grade) gypsum separatorWith Ø38mm threaded inlet and outlet fittings, removable quick release container with drain valve and handle. Cantilever brackets for wall fixing.
GEC Anderson Data Sheet - Edge 8
Anderson, GEC Ltd
GEC Anderson® side/back turn-down edge (8). Standard height: 20mm (Option: 8 - 250mm). See also GEC Anderson® edge (6) and edge (7).
GEC Anderson Data Sheet - Sink Bowl: LR38
Anderson, GEC Ltd
The LR38 is one of the GEC Anderson® standard range of circular individual stainless steel sinks.
• Internal bowl size: Ø380mm
• 20 mm flat flange (Overall size: Ø420mm)
• Fixing options: Undermount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow • Sound deadended and plastic protected
GEC Anderson Data Sheet - G94 (200) Single Bowl
Anderson, GEC Ltd
Technical data sheet for GEC Anderson stainless steel single bowl: 860x420x200mm.
The bowl is complete with Ø38mm waste and overflow fittings.
Can be configured as required.
GEC Anderson Data Sheet - Sink Bowl: T18
Anderson, GEC Ltd
The T18 is one of the GEC Anderson® standard range of individual stainless steel sinks.
• Internal bowl size: 180x380x160mm
• Fixing options: Undermount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow • Sound deadended and plastic protected
GEC Anderson Data Sheet - Series A sink: AD40T
Anderson, GEC Ltd
The AD40T is one of the GEC Anderson® Series A range of double stainless steel sinks, including tap landing. Series A sinks are of the highest quality and finish and are available in single, double and combination sizes.
• Internal bowl size: 400x400x200mm with 12mm corner radius • 90mm tap landing with Ø35mm taphole
• 20 mm flat flange (Overall size: 865x510mm)
• Fixing options: Undermount / Inset / Flushmount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow • Sound deadended and plastic protected
GEC Anderson Data Sheet - Series A sink: A74
Anderson, GEC Ltd
The A74 is one of the GEC Anderson® Series A range of individual stainless steel sinks. Series A sinks are of the highest quality and finish and are available in single, double and combination sizes.
• Internal bowl size: 740x400x200mm with 12mm corner radius • 20 mm flat flange (Overall size: 780x440mm)
• Fixing options: Undermount / Inset / Flushmount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow fittings • Sound deadended and plastic protected
GEC Anderson Data Sheet - Sink Bowl: LR37
Anderson, GEC Ltd
The LR37 is one of the GEC Anderson® standard range of circular individual stainless steel sinks.
• Internal bowl size: Ø370mm
• 25 mm flat flange (Overall size: Ø420mm)
• Fixing options: Undermount / Inset
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow • Sound deadended and plastic protected
GEC Anderson Data Sheet - Taphole
Anderson, GEC Ltd
GEC ANDERSON® TAPHOLES
Tapholes can be provided in any size or position.
• Standard size: Ø35mm for mixer tap; Ø30mm for pillar taps • Standard position from back of sink: 50mm to taphole centre
GEC Anderson Data Sheet - Sink Bowl: T22
Anderson, GEC Ltd
The T22 is one of the GEC Anderson® standard range of individual stainless steel sinks.
• Internal bowl size: 220x400x160mm
• Fixing options: Undermount
• EN 1.4301 brushed satin stainless steel
• Ø89mm basket strainer waste (BSW) and overflow • Sound deadended and plastic protected
GEC Anderson Data Sheet - G33 Single Bowl
Anderson, GEC Ltd
Technical data sheet for GEC Anderson stainless steel single bowl: 330x330x170mm.
The bowl is complete with Ø38mm waste and overflow fittings.
Can be configured as required.
GEC Anderson Data Sheet - DR217 (DG65)L Double Bowl With Drainer
Anderson, GEC Ltd
DR217 (DG65) Decimetric® 2100x700mm - double bowl, single drainer - commercial grade stainless steel sinktop. 40mm lipped front and side edges and 100x20mm rear upstand. Bowl size: 600x500x320mm deep complete with Ø38mm outlet and overflow fittings. Sound deadened and plastic protected. (EN 1.4301 grade stainless steel). LH drainer.
