09.3053 Dolphin Horizontal Bin Flap
Verified by manufacturer 3 months ago
09.3046 - Wall mounted
09.3046 - Wall mounted
Stainless steel waste bin flap for use with an under counter waste bin.
Application
Suitable for use with under counter waste bins.
Description
Horizontal stainless steel waste bin flap.
Features and benefits:
- Brushed satin finish.
- Horizontal.
- Manufactured from grade 1.4301 (304) stainless steel.
General information
Color | Silver |
Finish | Brushed |
Material | Stainless steel |
Shape | Rectangle |
Width | 290 mm |
Height | 170 mm |
Warranty description | One year Guidance for specification option: Covered by a 12-month warranty from the date of purchase to be free from defects if installed and maintained in accordance with instructions. |
Uniclass | |
CAWS | N13/474 Waste bins |
Specification data - Waste bins
Form | Wall mounted waste flap, hinged. |
Materials | Stainless steel.Guidance for specification option: Grade 1.4301 (304). |
Finish and colour | Brushed satin. |
Size | 290 x 170 x 6 mm.Manufacturer guidanceHeight x width x projection. |
Weight (approximate) | 1 kg. |
Operation | Sprung loaded piano hinge. |
Opening | 250 x 130 mm. Manufacturer guidanceRecommended wall/ door opening (width x height). |
Fixing holes | Punched fixing holes Ø 5. Guidance for specification option: In sides. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
