400 Series Fully Integrated 60 cm Dishwasher
Verified by manufacturer 5 months ago
DF480101 400 series, 8 Programme, 4 Option, Push-to-Open, Zeolite, fully integrated 81.5 cm, Home Connect
DF480101 400 series, 8 Programme, 4 Option, Push-to-Open, Zeolite, fully integrated 81.5 cm, Home Connect
Application
Washing application.
Description
400 series dishwasher, 60 cm. Also available with flexible hinge option for special installation applications.
Features and benefits:
- Home Connect.
- Optimal protection for sensitive glassware.
- Flexible basket system.
- Push-to-open function for perfect integration into handleless furniture fronts.
- Perfectly illuminated interior.
- Glass protection with zeolite.
- Aqua sensor.
- Load sensor.
- Detergent recognition.
- Regeneration electronics.
- Heat exchanger.
- Continuous flow heater.
- Triple filter system.
- Soft lock.
- Aqua stop.
- Maximum dish sizes (upper/lower basket) 27/25, 24.5/27.5 or 22/31 cm respectively.
- 12 place setting capacity.
- Maximum glass loading capacity 23 wine glasses.
General information
Color | White |
Material | Stainless steel |
Shape | Rectangle |
Length | 550 mm |
Width | 600 mm |
Height | 875 mm 815 mm |
Warranty description | Five year |
Uniclass | |
CAWS | N11/360 Appliances N11/40 Appliances |
Specification data - Domestic dishwashers
Installation | Integrated. |
Arrangement | Full sized (12–15 place settings). |
Dimensions | |
Height (maximum) | 815 mm. |
Width (maximum) | 600 mm. |
Depth (maximum) | 550 mm. |
Rating | Total connected load 2000-2400 W. |
Water connections | Water connection with 3/4" screw joint. |
EU energy label rating (minimum) | B. |
Water consumption (maximum) | 9.5 L. |
Noise level at 1 m (maximum) | 43 dB (re 1 pW). |
Programmes | |
Number (minimum) | Eight. |
Wash temperatures | Auto 35 °C - 45 °C. Auto 45 °C - 65 °C. Auto 65 °C - 75 °C. Intensive 70 °C. Eco 50 °C. Night programme. Quick wash 45 °C (35 min.). Personalisation function (default setting: Pre-rinse). |
Features | Programmes: Intensive Plus. Power. Half Load. Hygiene. |
Special features | Height-adjustable feet. |
Sustainability data
Material | Stainless steel |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
The Models and Dimensions 2024 Edition l
The Range 2024
