5500 luxury offers a soft velour effect carpet sheet with a heavy contract suitable finish.
For use across the commercial, educational and public sectors.
A soft velour effect carpet sheet with a heavy contract suitable finish. Made of a mix of polypropylene and nylon solution-dyed fibres.
Features and benefits:
Color | Black Blue Red Green Turquoise Manufacturer guidanceWide range available. |
Material | Fibre Guidance for specification option: 85% Polypropelene 15% Nylon |
Shape | Rectangle |
Length | 30000 mm |
Width | 2000 mm |
Height | 6.5 mm |
Warranty description | 15 year |
Uniclass | |
CAWS | M50/170 Carpeting M50/25 Carpeting |
Standard | To BS EN 1307. |
Classification | |
Level of use class | To BS EN 1307, class 33. |
Recycled content | 25% (minimum) to BS EN ISO 14021. |
Width | 2000 mm. |
Colour and pattern | 0922 assyrian jade.0923 iceni blue.0928 saxon blue.0936 phoenician green.0940 armenian grey.0945 trojan green.0950 norman steel.0955 dorian azure.0956 spartan mauve.0960 barona blue.0961 sky dancer.0962 red lake.0966 navajo mauve.0970 yakama slate.0981 bavarian blue.0982 mayan sky.0983 norse green.0990 persian purple.11588 syracuse sun. |
Weight | 1150 g/m². |
Thickness | 8 mm. |
Length | 30 m. |
Flammability | Euroclass Efl-s1. |
Castor chair rating (to BS EN 985) | Pass. Guidance for specification option: Suitable for continuous use. |
Static electricity | Body voltage test (to BS ISO 6356:2000): <2 kV. |
Sound performance | Reduction in impact noise (to BS EN 140-8:1998): 21 dB. |
Colour fastness | Light (to BS EN ISO 105 – BO2): grade 6 (minimum); shampoo (to BS 1006: UK-TB:1990): grade 4 (minimum). |
Thermal resistance | Tog rating 0.89; ISO 8302: 0.09 m²K/W. |
Environmental specifics | EPD-assessed. |
Castor chair rating | Pass. |
Dynamic loading | Loss <20%>. |
Noise | 21 dB. |
Noise at 1000 Hz | 30.7 dB. |
Sound absorption coefficient | BS EN 354:2003. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Fibre Guidance for specification option: 85% Polypropelene 15% Nylon |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 3.73 kg CO₂ eq/m² |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 55 % |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
Revit 2016 | 4 | |
- | 3 |
