Aerolux Tilting and Retractable Louvred Roof

Verified by manufacturer 6 months ago

Breezefree Ltd

Retractable louvred roof.

Jump to:
+44 (0)20 8877 3030 Website

Application

The system is designed to be suitable for outdoor living areas, and is particularly suitable for hospitality venues such as restaurants, hotels or cafes, and residential installations.


Possibility of installation as lean-to or self-standing makes this pergola a sustainable solution for terraces, patios, roof terraces, balconies, pool houses, hot tubs and outdoor kitchens and dining areas.

Description

Aerolux is an innovative bioclimatic pergola system with full-automatic tilting / retractable aluminum louvres and provides excellent protection from the sun and rain all the while providing beneficial ventilation.


Aerolux bioclimatic pergola system is a modern choice that adds value to outdoor living areas. The system is designed to be adapted to any kind of outdoor living area, providing a high degree of visual appeal and shelter.


Features and benefits:

  • Suitable for large and small areas alike.
  • Ground-fixed aluminium louvres construction.
  • Integrated guttering.
  • Options for adjustable glass sides and flexible screens.
  • The Aerolux model is 100% waterproof and draught-proof.
  • The louvres in dimensions 180 x 40 mm are made from a special aluminum alloy which ensures exceptional strength.
  • The louvres form a flat and smooth ceiling, draining the rainwater to the discrete gutter and downpipe in fully closed position.
  • The construction of the system, with 160 x 160 mm posts, allows a high degree of resistance to strong winds and wide span between support columns.
  • Several modules can be linked to each other and an even larger patio roof can be created by coupling multiple modules lengthwise.

General information

Color

White

Cream

Beige

Yellow

Orange

Show more

Finish

Powder-coated

Material

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Uniclass

Pr_20_65_78_58 Open-sided sheltersPrimary

CAWS

B91/370 Pergola/ arbour

B91/330 Canopy

Specification data - Open-sided shelters

Shelter description

Tilting louvred roof.

Tilting and retractable louvred roof.

Dimensions

-

Plan size

Guidance for specification option:

Consult manufacturer and insert requirements.

  • Maximum width: 4000 mm.
  • Maximum projection: 6000 mm.
  • Louvred roof structures can be coupled to achieve greater coverage.

Height

Guidance for specification option:

Consult manufacturer and insert requirements.

  • Max: H +30 cm.

Frame

-

Material

Aluminium alloy.

Colour

Pure white.

Pearl white.

Beige.

Quartz grey.

Sepia brown.

Wine red.

Signal red.

Sulfur yellow.

Traffic green.

Moss green.

Sky.

Cobalt blue.

Jet black.

Traffic grey.

Roof covering

Aluminium - louvred.

Openings

-

Doors

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Integral services

Mains electricity.

Rainwater drainage

Guidance for specification option:

The louvres form a flat and smooth ceiling and drain the rainwater to the discrete gutter in fully closed position.

Accessories

Not required.

Rain sensor.

Wind sensor.

Sun sensor.

Remote.

Post

160 x 160 mm.

Louvre blades

180 x 40 mm.

Configuration

Free standing.

Lean-to.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Turkey

Recyclability

Aluminium frame, louvres and legs can all be recycled at any metal recycling centre.

Literature

Louvred Roof

Louvred Roof
