Name: Altro Illustra™ - Safety Flooring
Brand: Altro
SKU: isthNXZLUW9HEBePND54kN

Verified by manufacturer 3 days ago

Color

Other

Finish

Matt

Material

Polyvinyl chloride (PVC)

Shape

Rectangle

Length

20000 mm

Width

2000 mm

Height

2 mm

Warranty description

Ten year

Uniclass

Pr_35_57_71_61 Particle-based enhanced slip-resistant polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/20 Sheeting

M50/150 Sheeting

Standard

To BS EN 14041 and BS EN 13845.

Backing

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Use class

To BS EN ISO 10874, Class 34/ 43.

Slip potential

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

PTV ≥36.
To EN 13893 ≥0.30/ DS.
To EN 16165 Annex B: R10.
To EN 13845 Annex C: ESf.

Surface roughness (Rz) (minimum)

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Recycled content

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Width

2000 mm.

Thickness

2 mm.

Colour and pattern

Soapstone - LU2417.

Keystone - LU2414.

Jurassic Slab - LU2418.

Canyon Clay - LU2413.

Skyfall - LU2415.

Hazy Twist - LU2409.

Gentle Twist - LU2414.

Midnight Twist - LU2411.

Bedrock - LU2412.

Sand Castle - LU2401.

Clay Bed - LU2402.

Highway - LU2403.

Ammonite - LU2416.

Accessories

Guidance for specification option:

Consult manufacturer for options and insert requirements or omit.

Sound insulation

To EN ISO 10140-3: ca. 4 dB.

Wear layer thickness

To EN ISO 24340: 0.7 mm.

Weight

To EN ISO 23977: 2.66 kg/m².

Residual indentation

To EN ISO 24343-1: ≤0.1 mm.

Flexibility

To EN ISO 24344: Pass.

Dimensional stability

To EN ISO 23999: ≤0.4%.

Lightfastness

To EN ISO 105-BO2: ≥6.

Castor chair rating

To ISO 4918: Yes, type W.

Wear resistance

To EN 13845 Annex D: ≤10% / 50 000 cycles; to EN 660-2: Group T.

Chemical resistance

To EN ISO 26987: Suitable.

Thermal resistance

To EN 12667: 0.01 m²K/W.

Electrical

To EN 1815: ≤2 kV antistatic.

VOC emissions

To CDPH 1350/ Indoor Air Comfort Gold M1: Approved.

Country of product manufacture

Europe

Material

Polyvinyl chloride (PVC)

Recyclability

100% recyclable pre installation - ALTRO RECOFLOOR™ https://www.recofloor.org/

Accessories	Guidance for specification option: Consult manufacturer for options and insert requirements or omit.
Sound insulation	To EN ISO 10140-3: ca. 4 dB.
Wear layer thickness	To EN ISO 24340: 0.7 mm.
Weight	To EN ISO 23977: 2.66 kg/m².
Residual indentation	To EN ISO 24343-1: ≤0.1 mm.
Flexibility	To EN ISO 24344: Pass.
Dimensional stability	To EN ISO 23999: ≤0.4%.
Lightfastness	To EN ISO 105-BO2: ≥6.
Castor chair rating	To ISO 4918: Yes, type W.
Wear resistance	To EN 13845 Annex D: ≤10% / 50 000 cycles; to EN 660-2: Group T.
Chemical resistance	To EN ISO 26987: Suitable.
Thermal resistance	To EN 12667: 0.01 m²K/W.
Electrical	To EN 1815: ≤2 kV antistatic.
VOC emissions	To CDPH 1350/ Indoor Air Comfort Gold M1: Approved.
