Aluprof MB-77HS ST - standard framed system, double track framed system
Cradle to Cradle Certified
Certificate type
EPD
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
ISO 9001 Quality Management
Certificate type
Qualicoat approval
Certificate type
Aluminium 'lift-and-slide' door system, available as manual or automated operation with thermal variants to achieve the best possible thermal performance.
The MB-77HS 'lift-and-slide' door is a solution for connecting interior space with the outside areas.
The product provides both smooth and silent slide action operation. In addition, by way of its design and operation, the MB-77HS provides a space-saving opening and does not encroach on the free space beyond the internal or external confines of the frame.
Providing high weathertightness, together with enhanced thermal performance, the MB-77HS complies with all of the requirements associated with this product type.
Available in two different thermal options, the MB-77HS is further categorised by 'ST' (standard) and 'HI' (highly insulated) variants.
The design and arrangement of the system profiles enable large opening dimensions with double or triple glazed units, which in conjunction with the constituent parts and innovative technical solutions create a high level of thermal and acoustic performance.
Features and benefits:
Performance:
Finish | Anodized Powder-coated |
Material | Aluminium |
Shape | Square Rectangle |
Length | Bespoke |
Width | Bespoke Manufacturer guidanceMaximum width up to 3300 mm per leaf |
Height | Bespoke Manufacturer guidanceMaximum height up to 3200 mm per leaf |
Warranty description | 25 year Guidance for specification option: (Up to 25 year.) Polyester powder coating finish. Consult manufacturer for details of marine and industrial environments. Ten year Guidance for specification option: Anodized. |
Uniclass | |
CAWS | L20/520 Sliding doors |
Third party accreditation | Manufacturer guidanceConsult manufacturer for details. |
Performance | Air permeability to EN 12207: Up to class 4. Wind load resistance to EN 12210: Up to class C4. Water tightness to EN 12208: Up to class 9A. |
Arrangement | 2 pane: fixed/slide.2 pane: slide/slide.3 pane: fixed/slide/fixed.3 pane: slide/fixed/slide.3 pane: fixed/slide/slide.3 pane: slide/slide/slide.4 pane: fixed/slide/slide/fixed.4 pane: slide/slide/slide/slide.6 pane: fixed/slide/slide/slide/slide/fixed.Other. |
Track system | Bottom loaded sliding door on integral track. |
Door leaves | |
Construction | Aluminium. |
Finish and colour | Anodized by Aluprof to Qualanod standard, natural silver.Anodized by Aluprof to Qualanod standard, coloured anodized to Aluprof 'C' range.Guidance for specification option: Insert colour requirements. Anodized by Aluprof to Qualanod standard, brushed silver anodized.Anodized by Aluprof to Qualanod standard, heavy brushed silver anodized.Polyester powder-coated by Aluprof to Qualicoat standard, RAL, matt.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, RAL, matt.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, RAL, matt.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, RAL, matt.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, RAL, satin gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, RAL, satin gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, RAL, satin gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, RAL, satin gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, RAL, high gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, RAL, high gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, RAL, high gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, RAL, high gloss.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, RAL, Structure.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, RAL, Structure.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, RAL, Structure.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, RAL, Structure.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, RAL, imitation anodized.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, RAL, imitation anodized.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, RAL, imitation anodized.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, RAL, imitation anodized.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, RAL, NCS.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, NCS.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, NCS.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, NCS.Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, Decoral (wood grain effect).Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, Decoral (wood grain effect).Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco standard, Decoral (wood grain effect).Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, Decoral (wood grain effect).Guidance for specification option: Insert colour requirements. Polyester powder-coated by Aluprof to Qualicoat standard, Special effects.Guidance for specification option: Includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, Special effects.Guidance for specification option: Includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Polyester powder-coated by Aluprof to Qualideco standard, Special effects.Guidance for specification option: Includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, Special effects.Guidance for specification option: Includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Bespoke.Guidance for specification option: Insert details of external and internal and coatings choices from the list above. Manufacturer guidanceAnodized finishes: 25 µm film thickness. Polyester powder-coated finishes: 60 µm film thickness. |
Operation | Manual.Slide.Manufacturer guidanceDependent upon variant selection. |
Hardware | Aluprof dedicated MB-77HS hardware only. |
Accessories | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Execution | Manufacturer guidanceSee also Installation below. |
Frame and architraves | Aluprof K range aluminium section. |
Glazing/ Infill details | Insulated glass units or Insulated metal panels. |
Perimeter seals | Guidance for specification option: Consult manufacturer for details and insert requirements. |
Thermal performance (U-value maximum) | From 0.84 W/m²K. Guidance for specification option: MB-77 HS HI from 0.84 W/(m²K) achieved with 3 x 2.9 m leaf, and glazing Ug: 0.5 W/(m²K) equipped with a Chromatech Ultra spacer. |
Fixing | Direct fix. Lug fixing. Glazing rebate into curtain wall system. |
Installation | The MB-77HS door system specified above shall be fabricated and installed by Aluprof approved companies only, in complete accordance with the information and guidance distributed by Aluprof UK Ltd. |
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Recyclability | Cradle to Cradle |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 59.57 % |
Cradle to Cradle Certified
Cradle to Cradle Certified™ - Bronze
EPD
Aluprof Environmental Product Declaration to EN 15804 - Window & Door Systems
ISO 14001 Environmental Management Systems
Aluprof ISO 14001 Certificate
ISO 9001 Quality Management
Aluprof ISO 9001 Certificate
Qualicoat approval
Aluprof Qualicoat Certificate 2022
