Architectural Fire Extinguisher Cabinets

Verified by manufacturer 5 days ago

Double Cabinet, Aluminium, Fully-Recessed - FEC4025F10 (106-1019)

Firechief Global Variant:

Recessed and semi-recessed fire extinguisher cabinets.

Jump to:
+44(0) 330 999 0019 Website

Application

Suitable for housing extinguishers in internal applications.

  • Recessed cabinets - particularly suited to the modern interior, for specification at design stage.
  • Semi-recessed cabinets - a neat option for the treatment of fire extinguishers where wall depth does not permit full recessing. They are a consideration for retro-fit type projects.

Description

The Firechief® architectural fire extinguisher cabinet range aids architects and designers in meeting the recommendations of legislation.


Features and benefits:

  • Available as recessed or semi-recessed options.
  • Comes in stainless steel, aluminium and white.
  • Clear acrylic glazed door.
  • Particularly suitable for design-led interiors.
  • Single or double cabinet capacity.
  • Single cabinets - designed to hold at maximum a single 6 litre water with additive extinguisher (typical rating 21A) or a 6 litre foam spray extinguisher (typical rating 13A 144B).
  • Double cabinets - designed to hold at maximum two of the above extinguisher types, or more commonly one of the above combined with one 2 kg CO2 extinguisher (typical rating 34B).

General information

Color

White

Silver

Finish

Smooth

Material

Aluminium

Steel

Stainless steel

Acrylic

Shape

Rectangle

Length

196 mm

Manufacturer guidance

Depth.

Width

390 mm

593 mm

Height

771 mm

Uniclass

Pr_80_77_28_29 Fire extinguisher cabinetsPrimary

Specification data - Fire extinguisher cabinets

Location/ type

Fully-recessed.

Material

Aluminium.

Size

771 x 593 x 196 mm.

Manufacturer guidance

Height x width x depth.

Door finish

Clear acrylic glazed door.

Cabinet

Double cabinet.

Sustainability data

Country of product manufacture

United Kingdom

Material

Aluminium

Steel

Stainless steel

Acrylic
