Architectural Fire Extinguisher Cabinets
Verified by manufacturer 5 days ago
Double Cabinet, Aluminium, Fully-Recessed - FEC4025F10 (106-1019)
Double Cabinet, Aluminium, Fully-Recessed - FEC4025F10 (106-1019)
Recessed and semi-recessed fire extinguisher cabinets.
Application
Suitable for housing extinguishers in internal applications.
- Recessed cabinets - particularly suited to the modern interior, for specification at design stage.
- Semi-recessed cabinets - a neat option for the treatment of fire extinguishers where wall depth does not permit full recessing. They are a consideration for retro-fit type projects.
Description
The Firechief® architectural fire extinguisher cabinet range aids architects and designers in meeting the recommendations of legislation.
Features and benefits:
- Available as recessed or semi-recessed options.
- Comes in stainless steel, aluminium and white.
- Clear acrylic glazed door.
- Particularly suitable for design-led interiors.
- Single or double cabinet capacity.
- Single cabinets - designed to hold at maximum a single 6 litre water with additive extinguisher (typical rating 21A) or a 6 litre foam spray extinguisher (typical rating 13A 144B).
- Double cabinets - designed to hold at maximum two of the above extinguisher types, or more commonly one of the above combined with one 2 kg CO2 extinguisher (typical rating 34B).
General information
Color | White Silver |
Finish | Smooth |
Material | Aluminium Steel Stainless steel Acrylic |
Shape | Rectangle |
Length | 196 mm Manufacturer guidanceDepth. |
Width | 390 mm 593 mm |
Height | 771 mm |
Uniclass |
Specification data - Fire extinguisher cabinets
Location/ type | Fully-recessed. |
Material | Aluminium. |
Size | 771 x 593 x 196 mm.Manufacturer guidanceHeight x width x depth. |
Door finish | Clear acrylic glazed door. |
Cabinet | Double cabinet. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Aluminium Steel Stainless steel Acrylic |
