Application

High security applications such as shopping centres, complexes, stadiums, sport centres, promenades, airports and ports.

Description

Hydraulic rising bollards are suitable for high security applications and preventing unauthorized vehicle access and providing an anti-ram solution. Rising bollards are also suitable for controlling vehicle access whilst allowing pedestrian free passage.


Rising bollards include a control cabinet, which is recommended to be installed within 10 m of the bollard system.


Features and benefits:

  •  100% duty rating; they will operate an unlimited number of cycles per hour.
  •  Provides a simple solution and added security to sites where vandalism is a risk.
  •  Traffic light System, with Industrial bulbs with failure sensor.
  • Security lock on cabinet door.
  • Reinforced hoses for long service with hydraulic seal.

General information

Color

Silver

Material

Carbon steel

Shape

Rectangle

Width

215 mm

Height

600 mm

Warranty description

One year

Uniclass

Pr_20_76_08_12 Carbon steel rising bollardsPrimary

CAWS

Q50/194 Retracting bollards

Q50/30 Street furniture

Product range

Perimeter Security Range

Specification data - Carbon steel rising bollards

Automation

-

Method of operation

Hydraulic Power Unit (HPU).

Electrical supply

230 V a.c.

Dimensions

-

Size and profile

600 x 215 mm.

Height

600 mm.

Top profile

Flat.

Base

Flat.

Finishes

-

Worked finish

Stainless steel finish.

Applied finish

Stainless steel finish.

Accessories

None.

100 mm diameter red/ green LED traffic light head - Highly recommended to be installed with all Bollard systems.

Signage.

Biodegradable oil.

Control pedestal - dual height.

Control pedestal - HGV height.

Control pedestal - standard height.

Hydraulic oil.

Reflective banding.

Access control

ANPR - Automatic number plate recognition.

Audio intercom.

Card reader.

Digital keypad.

GSM intercom.

Show more

Type

Rising/ Retractable.

Actuation

Audible alarms.

Flashing beacons.

Induction loop/ Vehicle detector loop system.

Lasers.

Light curtain.

Show more

Operating time

5-9 seconds depending on configuration.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0 kg CO₂ eq/unit

Self declared

Recyclability

100

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %
