Ball Stop Fencing - Sports fencing

Verified by manufacturer 5 months ago

Jacksons Fencing Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

Fencing designed for use in sports areas.

Jump to:
0800 408 4757 Website

Application

Sports areas; schools; parks; cricket; golf; football; rugby.

Description

Fencing designed for use in sports areas.


Features and benefits:

  • Extra-strength lattice posts and tubular construction for rigidity and ease of installation.
  • Top rail as standard.
  • Hollow, tubular construction.
  • Optional stainless steel tensioning wires at top and bottom of webbing/ mesh.
  • Strong, stable and safe structure, even in higher wind loading situations.
  • Lightweight and easy to install.
  • ‘Taut' webbing/ netting structure.
  • Suitable for polypropylene webbing, chain link and steel mesh infill.
  • Universal frame for various applications from rugby pitch to golf driving range.
  • Reduces risk of damage and injury claims.
  • Post tops can be adapted for lighting or camera mounts.
  • 25-year service life guarantee on posts and top rail.

General information

Color

Green

Black

Other

Finish

Galvanized

Powder-coated

Material

Steel

Width

3000 mm

Height

4000 mm

5000 mm

6000 mm

7000 mm

8000 mm

Show more

Warranty description

25 year

Uniclass

Ss_25_14_52_15 Continuous mesh fencing systemsPrimary

CAWS

Q40/125 Open mesh steel panel general purpose fencing

Q40/27 Open mesh steel panel general purpose fencing

Q40/30 Proprietary fencing

Q40/340 Steel vertical bar fencing

Q40/430 Proprietary fencing

Product range

Sports Fencing

Specification data - Continuous mesh fencing systems

Posts

Paired 60.3 mm-diameter steel posts.

Guidance for specification option:

With 12 mm steel lattice coupling.

Manufacturer guidance

See Worked finish below for colour/ finish options.

Post foundations

Base-plated 150 mm below ground level.

Wire

Stainless steel.

Polyethylene.

Steel chain link.

Fence topping

Tubular top rail.

System accessories

None.

Matching gates.

Guidance for specification option:

To be specified separately.

Stainless steel tension wires.

Guidance for specification option:

For use at top and bottom of webbing/ mesh.

Height

4000 mm.

5000 mm.

6000 mm.

7000 mm.

8000 mm.

Show more

Worked finish

Galvanized.

Guidance for specification option:

Standard.

Powder-coated, black RAL 9005.

Powder-coated, green RAL 6005.

Powder-coated, other.

Guidance for specification option:

On request; consult manufacturer for details and insert requirements.

PVC coated.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015 Quality Management System

Literature

Sports Fencing and Tubular Systems Fencing

Sports Fencing and Tubular Systems Fencing
