Beplas Elite FRP - Fire Rated
Hygienic fibreglass reinforced wall cladding.
Panels are designed for interior wall finishes where a high impact, hygienic, easy to clean surface is required, such as:
Fibreglass with polyester resin gives distinctive properties when it comes to strength to weight ratio, it will not shatter and provides high chemical resistance. Offers an alternative to traditional wall protection products with added benefits.
The sheets can be installed using traditional PVC extrusions or Beplas’ distinctive cold weld. They can be laminated to a variety of substrates for modular installation or cut into ceiling tiles. Elite FRP meets or exceeds UK, EU and Global hygiene, fire and building regulations.
Features and benefits:
Color | White |
Finish | Embossed Smooth |
Material | Fiber-glass Polyester Plastic |
Shape | Square Rectangle |
Length | 595 mm 1195 mm 2400 mm 3000 mm Bespoke |
Width | 595 mm 1200 mm Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | K13/145 Proprietary plastics cladding K13/145 Proprietary plastics cladding |
Material | Fibreglass reinforced plastic. |
Thickness | 2.3 mm. |
Sheet size | 595 x 595 mm.Guidance for specification option: Fire rated only. 1195 x 595 mm.Guidance for specification option: Fire rated only. 1200 x 2400 mm.1200 x 3000 mm. |
Finish | Embossed.Smooth. |
Colour | White. |
OperationalTemperatureRange | -40°C to +65°C. |
Flexural strength | 10 000 PSI. Manufacturer guidance(To ASTM D790) |
Tensile strength (minimum) | 7000 PSI. Manufacturer guidance(To ASTM D638) |
Barcol hardness | 35. Manufacturer guidance(To ASTM D2583) |
Coefficient of linear expansion (to ASTM D-696) | 2.22 x 10^-5 in/inï°F. Manufacturer guidance(To ASTM D696) |
Water absorption | 0.72%/72 hrs at 25°C. Manufacturer guidance(To ASTM D570) |
Abrasion resistance | 0.391% maximum weight loss. Manufacturer guidance(Taber test) |
Specific gravity | 1.5743. Manufacturer guidance(To ASTM D792) |
Fixing | Be-plas adhesive. Be-plas high impact thermoplastic drive rivets. GPPA600. Multibead. |
Accessories | None. Abutments. Guidance for specification option:
Be-plas FDA approved silicone sealant (Ref. PSNW600). Guidance for specification option: For mouldings and around all panel edges and fixtures. |
Corner detail | Internal IA252.4 - High impact PVC angles, 2440 x 25 x 25 mm. Internal IA253.0 - High impact PVC angles, 3050 x 25 x 25 mm. Internal IA382.4 - High impact PVC angles, 2440 x 38 x 38 mm. Internal IA383.0 - High impact PVC angles, 3050 x 38 x 38 mm. Internal IAL502.4 - High impact PVC angles, 2440 x 50 x 50 mm. |
Joint | DB242.4 - High impact PVC division bars, 2440 mm. DB243.0 - High impact PVC division bars, 3050 mm. TDB2.4 (two-part flex edge) - High impact PVC division bars, 2440 x 2.5 mm. TDB3.0 (two-part flex edge) - High impact PVC division bars, 3050 x 2.5 mm. Not required. Manufacturer guidanceJoint detail. |
Edge detail | CS242.4 - High impact PVC capping sections, 2440 mm. CS243.0 - High impact PVC capping sections, 3050 mm. TCS32.4 (rigid edge) - High impact PVC capping sections, 2440 x 3.0 mm. TCS33.0 (rigid edge) - High impact PVC capping sections, 3050 x 3.0 mm. Not required. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
- | 1 | |
- | 1 |
