Biopod IPS Systems
Verified by manufacturer 5 months ago
Biopod IPS Systems
Application
Biopod IPS Systems
Description
- Completely bespoke to your specification
- Rigid, totally impervious to water core
- 10 – 15 working days lead time (from sign off from
- production drawing)
- One piece construction - no dirt & bacterial traps
- No onsite framing required
- Minimising trades on site – saving you time
- and money
- Pre-formed internal/external radius corners
- Hinged and lockable access panels - standard or
- bespoke locks, flush or lipped access to suit
- BioClad proven antimicrobial lined
- Extensive colour range
- Predrilled to suit sanitary ware specification.
General information
Color | White Brown Orange Green Yellow |
Finish | Satin |
Material | PVC |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 20 year |
Uniclass | |
CAWS | K13/160 Proprietary K32/15 Duct/ wall lining panels K32/150 Duct/ wall linings – panels and proprietary frames N13/30 Washbasins N13/335 Washbasins |
SKU Code | Biopod |
Specification data - Duct and wall panel lining systems
Classification data | |
System performance | Fire performance of wall lining system to BS 476. |
Fasteners | 15 mm PVC core. |
Supporting frame | |
Wall panels | 15 mm PVC core. |
Execution | Preparation of substrates to receive wall linings. |
Height | Guidance for specification option: Consult manufacturer and insert requirements; maximum 3000 mm. |
Colour | Satin White LRV 88. Oyster LRV 71. Green LRV 75. Cream LRV 71. Mint LRV 60. Blue LRV 64. Grey LRV 57. Linen LRV 83. Cesco LRV 72. Seafoam LRV 81. Fawn LRV 39. Verona LRV 68. Cloud LRV 53. Malva LRV 68. Vivid Purple LRV 4. Vivid Pink LRV 17. Vivid Red LRV 7. Vivid Orange LRV 17. Vivid Olive LRV 37. Vivid Green LRV 47. Vivid Blue LRV 29. Vivid Black LRV 1. Vivid Lime LRV 59. Vivid White LRV 88. Vivid Royal LRV 15. Vivid Steel LRV 10. Vivid Taxi Cab Yellow LRV 51. Vivid Aqua LRV 40. Manufacturer guidanceWhite as standard, others available. Consult manufacturer and insert requirements. |
Maximum temperature | 60°C. |
Volatile organic compounds (VOC) content | 0. |
Samples required | Mock-up. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | PVC |
Recyclability | 100% Guidance for specification option: The recyclability is 100% given for Trovidur® EC-Clad, as long as the protective film is removed and the material is free from contamination like adhesive residues e. Manufacturer guidance100&% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 2 |
 Revit | - | 2 |
Literature
Biopod IPS Brochure
