Cabrillant 600 and 700 Cubicles - Solid Grade Laminate

Verified by manufacturer 5 months ago

Prospec Ltd

Highly engineered frameless cubicle in solid grade laminate for use in wet or dry areas.

Jump to:
+44 (0)1709 377147 Website

Application

Suitable for showers, changing areas and WCs.

Description

Cubicle systems designed for use as shower, changing and toilet cubicles in wet or dry areas, constructed from Solid Grade Laminate. The surface is easy to clean and withstands wet use. The aluminium fittings and components have been specifically engineered to overcome the weakness normally encountered in patch fitting systems.



Cubicles are available with or without doors, or optionally with coloured heavy-duty curtains. When installed as dividers without doors, shower cubicles are fixed with a small front pilaster panel and a continuous head rail to maintain stability and safety.

General information

Color

Silver

Finish

Satin

Guidance for specification option:

Satin Silver Anodized.

Anodized

Material

Laminate

Guidance for specification option:

Solid Grade Laminate.

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Uniclass

Ss_25_12_60_60 Panel cubicle systemsPrimary

CAWS

K32/10 Panel cubicles

K32/120 Panel cubicles

Specification data - Panel cubicle systems

Panels

12 mm Solid Grade Laminate.

Pilasters

12 mm Solid Grade Laminate.

Doors

12 mm Solid Grade Laminate.

Lippings

All edges polished all round, exposed corners with small radius.

Hardware

Fittings, Head Rail, Legs and Ironmongery/ Accessories.

Guidance for specification option:

  • Fittings: Satin anodized aluminium hinge/ brackets bonded with structural resin and fixed into concealed rosettes for added strength, to doors and pilaster panels.
  • Head Rail: Satin anodized aluminium overhead stabilizing bars fixed into concealed rosettes to top edge of pilaster panels, and satin anodized connector to top edge of partition panels.
  • Legs: One attached to partition panel 180 mm inboard with through fixings from satin anodized aluminium and stainless steel, with mechanical connection to front pilaster with adjustable ground clearance. Fixed to floor with 316 grade stainless steel screw and plastic plug.
  • Optional Bonded Leg: One attached to partition panel 180 mm inboard with through fixings from satin anodized aluminium and stainless steel, with mechanical connection to front pilaster with adjustable ground clearance. Fixed to floor with 316 grade stainless steel pin 10 mm long and high strength waterproof adhesive.
  • Ironmongery/ Accessories: Engineered satin anodized lock, fixed through door with concealed fixings with outside indicator and emergency release function. Lock finger engages into compatible lock receiver, fixed to pilaster panel. Available in choice of finishes to match extruded profiles. Satin anodized aluminium coat hooks with integral rubber buffer, through-fixed onto division panel for added strength and to perform as door buffer.


Curtains

Heavy duty antibacterial.

Guidance for specification option:

Available on request.

Anti-mould.

Guidance for specification option:

Available on request.

Commercial curtains.

Guidance for specification option:

Available on request.

Samples required

Not required.

Required.

Guidance for specification option:

Available on request.

System accessories

Anti-peep rails.

Glass corner shelf.

Wet/dry dividing fin.

Towel rail.

DDA handle.

Bench seating.

Knob and keep.

Hydraulic door closers.

Aluminium coat hook.

Door restraint.

Type

Cubicle.

Changing.

WC.

Shower.

Colour/ Finish

Not required.

Opaque Ceramic Painted Glass, Colour.

Translucent Ceramic Etched Glass.

Translucent Glass.

Toughened and Laminated Glass.

Configuration

Not applicable.

Guidance for specification option:

For curtains, or if no door is required.

Inward.

Outward.

Seats

None.

12 mm Solid Grade Laminate Bench Seats.

Duct system

Not required.

Trojan Duct Panel System (Aluminium Framed).

Guidance for specification option:

To be specified separately.

Cubicle height (overall)

2050 mm.

Guidance for specification option:

Non-standard sizes available on request, consult manufacturer and insert requirement.

Floor

-

Manufacturer guidance

Floor clearance: Non-standard sizes available on request, consult manufacturer and insert requirement.

Sustainability data

Contains Red List materials

No

Country of material origin

-

Manufacturer guidance

Europe Mix.

Country of product manufacture

United Kingdom

Recyclability

Laminate

Manufacturer guidance

Medium.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

Solid Grade Laminate, Aluminium.
