Century Speed Gates
Verified by manufacturer 1 month ago
CENTURY – CH 305
CENTURY – CH 305
QA Certificate
Certificate type
Achilles Information Limited - Procurement Management
Certificate type
ADSA
Certificate type
Alcumus SafeContractor
Certificate type
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
CHAS
Certificate type
Constructionline Gold
Certificate type
Motor driven speed access control gate.
Application
Suitable for advanced security in areas such as:
- Construction sites.
- Stadiums.
- Government buildings.
- Public transport areas.
- Retail outlets.
- Gyms.
Description
Motor driven speed access control gate. Variants in gate and design with optional finishes and accessories.
Features and benefits:
- Speed gate with fast-opening hidden barrier wings made of 10 mm tempered glass.
- Galvanized coated steel frame and stainless steel housing panels.
- 10 mm tempered glass top lid.
- Illuminated indication pictograms.
- DC motor driven
General information
Color | Beige Black Blue Bronze Brown |
Finish | Stainless steel Galvanized Powder-coated |
Material | Stainless steel Steel Glass |
Shape | Oval |
Length | 1485 mm 1500 mm |
Width | 1189 mm 1210 mm 2080 mm |
Height | 1005 mm 1011 mm |
Uniclass | |
CAWS | L10/690 Security L10/60 Security L20/490 Automatic doors Q50/160 Turnstile |
Specification data - Half-height access control gates
Properties | |
Safety features | Fail-safe and fail-locked.Guidance for specification option: The gate opens the barrier wings (fail-safe). During power-failure, the mechanism and barrier wings do not operate (fail-locked). The gate resets itself automatically when the emergency alarm stops or the power is switched back on. Fail-safe and optional battery unit.Guidance for specification option: The gate opens the barrier wings (fail-safe). Optional battery unit in order to open the wings during a power failure. The gate resets itself automatically when the emergency alarm stops or the power is switched back on. |
Configuration | Two-lane, left-hand operation. |
Housing | |
Type | Stainless steel solid panels with galvanized steel frame. |
Material and finish | Stainless steel. |
Colour | Standard, stainless steel.Guidance for specification option: As standard. Black, stainless steel.Guidance for specification option: Optional. Bronze, stainless steel.Guidance for specification option: Optional. Gold, stainless steel.Guidance for specification option: Optional. |
Panel | |
Type | Bi-parting rectangular wings. |
Rotation | Sliding. |
Material and finish | 10 mm tempered glass.Guidance for specification option: As standard. Acrylic.Guidance for specification option: Optional. |
Size | |
Clear opening width (minimum) | 550 mm. |
Overall width | 2080 mm. |
Length | 1500 |
Height | 1800 mm from FFL to top of panel. |
Security | Audible alarm. |
Credential Reader | |
Type | RFID.Guidance for specification option: As standard. Card inserter mounting.Guidance for specification option: Optional. Access controller integration mounts.Guidance for specification option: Optional. |
Controls | Stand-alone electronic access or building access control system. |
Control unit | integral or external to control gate. |
Power supply | Mains, 100–240 VAC 50–60 Hz.Guidance for specification option: As standard. Mains, 100–240 VAC 50–60 Hz with battery unit.Guidance for specification option: Optional, for fail safe during power cuts: allows gate to open and remain open. |
Communications | RS232 and RS485 serial interface. |
Accessories | Not required.Logo on barrier wings.Stainless steel base plate. |
Ingress protection (IP) rating | IP44. |
Weight | 165 kg. |
Sustainability data
Material | Stainless steel Steel Glass |
