Chaucer Flag Paving

Verified by manufacturer 4 months ago

Brett Landscaping Third party certifications:
  • EPD

    EPD

    Certificate type

Finely textured paving flags providing attractive, practical patio paving options.

Jump to:
+44 (0)345 60 80 570 Website

Application

Domestic use only; pedestrian pavements including home patios, pathways and internal floor coverings. They are not designed for vehicular trafficking or commercial applications.

Description

Finely textured paving flags providing attractive, practical patio paving options. Available in three popular colours and two sizes.


Standards:

Brett Landscaping operate a number of independently audited management systems:

  • BS EN ISO 9001: 2008 Quality Management System.
  • BS EN ISO 14001: 2004 Environmental Management System.
  • OHSAS 18001: 2007 Health and Safety Management System.
  • BES 6001 Responsible Sourcing of Construction Products.

General information

Color

Grey

Guidance for specification option:

Natural/ Charcoal.

Yellow

Guidance for specification option:

Buff.

Finish

Textured

Material

Concrete

Guidance for specification option:

Precast (hydraulically pressed).

Shape

Square

Length

450 mm

600 mm

Width

450 mm

600 mm

Height

32 mm

35 mm

Uniclass

Pr_25_93_60_16 Concrete flagsPrimary

CAWS

Q25/31 Concrete flag paving systems

Q25/315 Concrete flags

Specification data - Concrete flags

Standard

To BS EN 1339: 2003.

Physical properties

-

Colour

Buff.

Guidance for specification option:

(BF).

Charcoal.

Guidance for specification option:

(CL).

Natural.

Guidance for specification option:

(GY).

Finish

Textured surface with square edge detail.

Profile

-

Flag type

Regular plan form.

Arrises

Square.

Dimensions and associated tolerances

-

Nominal sizes

450 x 450 x 32 mm.

Guidance for specification option:

Typical unit weight: 28 kg.

600 x 600 x 35 mm.

Guidance for specification option:

Typical unit weight: 14 kg.

Tolerances on plan dimension and thickness (nominal)

Thickness: ±3 mm; Plan size ±2 mm.

Arrises

Square.

Weathering resistance

Class 3.

Abrasion resistance

Class 3.

Guidance for specification option:

≤23 mm, determined by Wide Wheel Abrasion test.

Slip resistance

USRV ≥55; Potential for slip: Low.

Bending strength

Class 2.

Guidance for specification option:

Characteristic bending strength ≥5.0 MPa.

Breaking load class

45.

Guidance for specification option:

Characteristic breaking load >4.5 kN.

Recycled content (minimum)

Guidance for specification option:

Manufacturer's standard.

Type

Hand lay.

Third-party certification

CE marked.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Concrete

Guidance for specification option:

Precast (hydraulically pressed).

Manufacturing plant location

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

11.35 kg CO₂ eq/m²

Recyclability

100%

Expected Life

40 year

Third party certifications

Third party certifications

EPD

EPD

Environmental Product Declaration - Paving Barrow

Literature

Chaucer Paving TDS Sept 21

Chaucer Paving TDS Sept 21
