Creation 40 Zen - LVT

Verified by manufacturer 3 days ago

1416 Bostonian Oak Beige

Gerflor Flooring UK Limited Variant:

Looselay all-in-one acoustic luxury vinyl tile delivering 20 dB sound insulation without an additional underlayer. Decorative, flexible, anti-static floor with 0.40 mm transparent wearlayer.

Jump to:
BOS
01625 428 922 Website

Application

Suitable for residential applications and small offices (European Class 32).

Description

CREATION 40 ZEN is an acoustic and decorative looselay floor, available in tile and plank format, with four bevelled edges. It comprises a 0.40 mm transparent wear layer and an enhanced surface treatment, Protecshield™, for improved micro-scratch and stain resistance, easy cleaning and an ultra matt finish. Available in 20 wood, mineral and material design references. All woods available as plank size 245 x 1250 mm. References 1479 Nature Oak Kraft and 1481 Nature Oak Taupe are also available in a herringbone plank size 150 x 750 mm. All mineral and material design references are available as tile size 500 x 500 mm. The range offers good design choice including mix and match options.


Features and benefits:

  • Durability- Suitable for residential applications and small offices (European Class 32).
  • Good range of design and colour options - 20 references. My Creation Zen custom designs also available subject to mmq.
  • Integrated acoustic layer delivering 20 dB sound insulation.
  • Slip resistant - R10.
  • Easy to install - Looselay product maintained with tackifier.
  • Available as tiles or planks.
  • 100% recyclable.
  • High level of indoor air quality - total volatile organic compounds (TVOC) after 28 days: <10 µg/m³.
  • Other products in the Creation 40 range include: Creation 40 LVT, Creation 40 Solid Clic and Creation 40 Rigid Acoustic (all specified separately).


Installation and maintenance:

  • Should be installed in accordance with the BS 8203:2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available.

General information

Color

Brown

Grey

Blue

Green

Pink

Show more

Finish

Matt

Material

Polyvinyl chloride (PVC)

Shape

Rectangle

Square

Length

500 mm

750 mm

1250 mm

Width

500 mm

150 mm

245 mm

Height

3.60 mm

Guidance for specification option:

Overall thickness.

Warranty description

12 year

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Product range

Tiles / Luxury Vinyl Tile (Flooring)

Specification data - Polyvinyl chloride (PVC) tiles

Standard

To BS EN 14041.

Use class

To BS EN ISO 10874 , Class 23-32.

Guidance for specification option:

Heavy domestic use - moderate commercial use

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Guidance for specification option:

To DIN 51130.

Size

245 x 1250 mm.

Thickness

3.60 mm.

Guidance for specification option:

To EN ISO 24346.

Colour and pattern

Bostonian Oak Beige.

Wear layer thickness

0.40 mm.

Guidance for specification option:

To EN ISO 24340.

Fire rating

Bfl-s1.

Guidance for specification option:

To BS EN 13 501-1.

Static electricity

<2 kV.

Guidance for specification option:

To BS EN 1815.

ThermalConductivity

0.25 W/mK.

Guidance for specification option:

To EN ISO 10456.

Surface treatment

ProtecShield™.

VOC emissions

<10 µg/m³.

Guidance for specification option:

To ISO 16000-6, TVOC after 28 days.

Wear group

T.

Guidance for specification option:

To QB 30

Impact sound reduction

20 dB.

Guidance for specification option:

To EN ISO 717-2.

Light reflectance value (LRV)

31.9.

Pack size

Plank size 245 x 1250 mm - 14 planks/box, 4.29m².

Plank size (herringbone) 150 x 750 mm - 38 planks/box, 4.28m².

Tiles size 500 x 500 mm -18 tiles/box, 4.5m².

Accessories

Matching skirtings

Paintable white skirtings

Matching coverstrips

Not required.

Sound absorption

<65 dB.

Guidance for specification option:

Room impact noise reduction to NFS 31 074.

Weight

2675 g/m².

Sustainability data

Contains Red List materials

No

Country of product manufacture

France

Recyclability

100 % recyclable.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Creation Zen – Brochure

Creation Zen – Brochure
