CS Acrovyn® PP-76 Stainless Steel Posts

Verified by manufacturer 11 months ago

Construction Specialties (UK) Ltd

Severe-duty stainless steel posts designed to protect architectural features, corners and doors by deflecting wheeled traffic away.

Jump to:
BOS
+44 (0)1296 652800 Website

Application

Severe-duty; protection of architectural features, corners and doors by deflecting wheeled traffic away.

Description

Severe-duty stainless steel posts designed to protect architectural features, corners and doors by deflecting wheeled traffic away.


Features and benefits:

  • Robust stainless steel posts designed for floor mounting.
  • Supplied with base plate cover to conceal fixings for a neat finish.
  • Available in a range of heights to suit application (900 mm as standard).
  • Complete with domed stainless steel cap.

General information

Color

Silver

Finish

Brushed

Material

Stainless steel

Width

200 mm

Guidance for specification option:

Base diameter.

Post diameter: 76 mm (cap diameter: 80 mm).

Height

900 mm

Bespoke

Guidance for specification option:

Posts can be cut to a smaller size if required.

Uniclass

Pr_35_90_43_86 Wall protection panelsPrimary
Pr_20_76_08_82 Stainless steel bollards

CAWS

N10/184 Wall rails

P20/170 Proprietary

Product range

CS Acrovyn Stainless Steel Solutions

Specification data - Wall protection panels

Material

Grade 304L stainless steel.

Finish

Brushed.

Colour or pattern

Silver.

Profile

Post.

Size

900 mm high.

Guidance for specification option:

Standard.

Other.

Guidance for specification option:

Insert required size: posts can be cut from 900 mm to suit requirements.

Manufacturer guidance

Base diameter: 200 mm.

Post diameter: 76 mm (cap diameter: 80 mm).

Fixing

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

CS Acrovyn Wall & Door Protection 2024

CS Acrovyn Wall & Door Protection 2024
