Demarcation Devices

Verified by manufacturer 4 months ago

Diamond rail fencing

Jacksons Fencing Variant:
Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

Timber posts with various rail options suitable for demarcation purposes.

Jump to:
0800 408 4757 Website

Application

Applications commonly include exclusive and rural new build homes, securing paddocks and livestock, or alternatively use around fields.

Description

Timber posts with various rail options suitable for demarcation purposes. Options include Diamond Rail/ Knee Rail/ Birdsmouth fencing, Silver Rail fencing and Post-and-chain fencing.


Features and benefits:

  • All timber used throughout is superior quality Jakcure® treated softwood guaranteed for 25 years.
  • Planed finish.
  • Manufactured in the United Kingdom.
  • Galvanized fixings for long life.

General information

Color

Other

Finish

Natural

Guidance for specification option:

Jakcure® treated.

Pre-treated

Material

Wood

Length

1800 mm

2700 mm

6000 mm

Height

900 mm

1200 mm

1500 mm

Warranty description

25 year

Guidance for specification option:

On timber products, the Jakcure® treatment process delivers a 25-year guarantee against all wood-boring pest and all forms of dry and wet rot.

Uniclass

Ss_25_14_63_97 Wood post and rail fencing systemsPrimary
Ss_25_15_60_97 Wood post and rail barrier systems

CAWS

Q40/30 Proprietary fencing

Q40/430 Proprietary fencing

Product range

Timber Fencing

Specification data - Wood post and rail fencing systems

Posts

900 mm-high (200900).

1200 mm-high (201000).

Manufacturer guidance

Birds mouth top, 100 x 100 mm section with a planed finish and galvanized strap secured to post with 50 mm nails.

Rails

1800 mm-long (640300).

2700 mm-long (640600).

Site applied finishes

-

Manufacturer guidance

Insert requirements or omit.

System accessories

None.

Galvanized strap (201100).

Jakcure end grain preservative.

Guidance for specification option:

Required to post treatment cutting or drilling.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Manufacturer guidance

North America

Country of product manufacture

United Kingdom

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015 Quality Management System
