Application

Fire and non-fire door edges.

Description

Door edge protectors to reduce damage to meeting and hinged edges of fire doors.

Features and benefits:

  • Available with a range of fire ratings.
  • Protectors are manufactured from extruded PVC-U, and are designed to reduce damage and maintenance costs to both fire and non-fire door edges.
  • Where a fire rating is required, the edge protectors incorporate intumescent strips.
  • All Door Edge Protectors are individually manufactured to suit each door thickness.

Approvals:

  • Patented Product - FD30/FD60.
  • BS 476: Part 22: 1987 - For 1/2 hour or one-hour fire integrity on full door assemblies. BS 476: Part 31.1: 1983 – To meet requirements of BS 5588.

VOC Emissions

Yeoman Shield PVC-U Falmouth Wall & Door Protection panels have been tested for VOC to ISO 16000-10:2006 Indoor air - Part 10.

The test showed the following results:

  • <10 µg/m²h for TVOC.
  • <5 µg/m²h for formaldehyde.



The interpretation of these results by BRE are if all the walls (less door and window) of the 30 m³ reference room described in BS EN 16515‑2017 (with a ventilation rate of 0.5 air changes per hour) were clad with Yeoman Shield PVC-U Falmouth Wall & Door Protection Panels, the increase in TVOC in the room would be <20 µg/m³ for TVOC and <10 µg/m³ for formaldehyde and these are deemed to be low.



BREEAM Hea 02 has limits of 300 µg/m³ for TVOC and 100 µg/m³ for formaldehyde, so the theoretical increases in TVOC and formaldehyde from using the PVC-U sheet are deemed as low.

General information

Color

Blue

Guidance for specification option:

  • Powder Blue BS 20 C 33 - stock colour
  • Pastel Blue RAL 5024 - stock colour
  • Regatta BS 18 E 53 - stock colour
  • Cornflower Blue RAL 5012 - stock colour
  • Royal Blue RAL 5017 (nearest) - stock colour
  • Dark Blue RAL 5002 - stock colour
  • Trafalgar Blue RAL 5000 - stock colour
  • Steel Blue RAL 5011- stock colour
  • Sky Blue - stock
  • Pigeon Blue BS 18 C 35 - stock colour


Green

Guidance for specification option:

  • Pale green BS 14 C 31 - to order
  • Sage green BS 14 C 35 (nearest) - stock colour
  • Pastel Green RAL 6019 - stock colour
  • Green BS14 E 53 - stock colour
  • Opal Green RAL 6004 - stock colour
  • Slate Green - to order
  • Light Green RAL 6027  - stock colour
  • Aqua Blue RAL 5018 - stock colour


Grey

Guidance for specification option:

  • Light Grey BS 00 A 01 - stock colour
  • Mid Grey BS 00 A 05  - stock colour
  • Dusty Grey RAL 7037 - stock colour
  • Graphite  RAL 7046 (nearest)- stock colour
  • Dark Grey RAL 7015- stock colour


Red

Guidance for specification option:

  • Raspberry Red RAL 3027 (nearest) - to order
  • Red BS 04 E 53 - stock colour
  • Burgundy RAL 3003 - to order
  • Bordeaux RAL 4004 - to order


Orange

Guidance for specification option:

  • Tangerine RAL 2012 (nearest) - to order
  • Terracotta - to order
  • Orange - to order


Show more

Manufacturer guidance

See manufacturers colour card

Finish

Textured

Material

PVC-U

Shape

Other

Length

Bespoke

Guidance for specification option:

Post formed, manufactured to suit.

Width

Bespoke

Guidance for specification option:

Post formed, manufactured to suit.

Height

2 mm

Guidance for specification option:

Thickness.

Uniclass

Pr_30_36_33_20 Door edge protectorsPrimary
Pr_35_90_33_22 Door and window weatherstrips and seals

CAWS

L20/230 Wood flush doors

L20/55 Doorsets

L20/420 Wood doorsets

L20/25 Wood panelled doors

L20/20 Wood flush doors

L20/410 Wood doorsets

L20/250 Wood panelled doors

Specification data - Door edge protectors

Third-party certification

To BS 476: Part 22: 1987 and BS 476: Part 31.1: 1983 – To meet requirements of BS 5588.

Material

Extruded PVC-U.

Guidance for specification option:

  • Outer surface: 2.0 mm extruded Vinylac, a specially formulated PVC-U.
  • Inner Core: 9 mm thick toughened PVC-U with 15 x 4 mm fire seal insert.

Profile

Radius.
Square.
Double swing.

Fire resistance

None.
30 minutes.

Dimensions

Guidance for specification option:

Insert requirements:

  • Individually manufactured to suit door size. For fire doors, will be within the parameters of test data.
  • 50 mm return legs recommended for optimal protection.
  • Up to 2150 mm lengths.

Colour

Cornflower blue.
Avocado.
Trafalgar blue.
Royal blue.
Amethyst.
Aubergine.
Heather.
Lavender.
Graphite.
Mocha.
Sage green.
Pale green.
Terracotta.
Raspberry red.
Opal green.
Light green.
Pastel green.
Pastel blue.
Aqua blue.
Steel blue.
Bordeaux.
Lilac.
Burgundy.
Blush
Pink rose.
Dusty grey.
Grapefruit.
Red.
Sky blue.
Orange.
Yellow.
Green.
Slate green.
Black.
Dark blue.
Regatta blue.
Powder blue
Pigeon blue.
Brown.
Buff.
Mushroom.
Cream.
White.
Dark grey.
Mid grey.
Light grey.
Primrose.
Tangerine.

Core

9 mm thick toughened PVC-U.

Facings

Falmouth.

Applied finish

Falmouth.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

PVC-U

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2016

3

IFC

IFC2X3

2
