Dorado Granite

Verified by manufacturer 2 months ago

Flamed Finish

Marshalls plc Variant:

Hard-wearing, strong and durable light to mid-grey granite from Portugal.

Jump to:
+44 (0)330 0574472 Website

Application

Suitable for both pedestrian and vehicular trafficked areas. Available across all product areas including Paving, Setts, Kerbs, Tactile, Steps, Water Management, Bespoke Street furniture, Masonry and Specials – allowing for the creation of unified schemes.

Description

Dorado Granite is a hard-wearing, strong and durable granite suitable for both pedestrian and vehicular trafficked areas. Predominantly light to mid-grey, Dorado Granite is available in three finish options – blasted, flamed and polished – to match different applications and their needs, whether they call for a smooth aesthetic or superior non-slip properties.


Features and benefits:

  • UKCA marked in accordance with the latest legislation.
  • Available in a range of standard plan sizes.
  • Bespoke size options can be accommodated upon request.

General information

Color

Grey

Finish

Blasted

Flamed

Polished

Material

Granite

Shape

Rectangle

Square

Length

450 mm

600 mm

900 mm

200 mm

300 mm

Show more

Width

450 mm

600 mm

100 mm

150 mm

200 mm

Show more

Height

50 mm

60 mm

70 mm

Bespoke

Uniclass

Pr_25_93_60_58 Natural stone paving slabsPrimary

CAWS

Q25/320 Tactile flags and slabs

Q25/26 Natural stone slab paving systems

Q25/310 Natural stone slabs

Specification data - Natural stone paving slabs

Standard

To BS EN 1341.

Stone denomination

-

Petrological family

Granite.

Guidance for specification option:

Pale grey to greyish white Granite with occasional black fine irregular biotite mica.

Colour

Grey, white background with black inclusions.

Origin

Portugal.

Guidance for specification option:

Quarry of origin: Corvaceira.

Physical properties

-

Profile

-

Slab type

Regular plan form.

Dimensions and associated tolerances

-

Nominal sizes

200 x 100 x 50 mm.

200 x 100 x 60 mm.

200 x 100 x 70 mm.

300 x 100 x 50 mm.

300 x 100 x 60 mm.

300 x 100 x 70 mm.

300 x 150 x 50 mm.

300 x 150 x 60 mm.

300 x 150 x 70 mm.

300 x 200 x 50 mm.

300 x 200 x 60 mm.

300 x 200 x 70 mm.

450 x 450 x 50 mm.

450 x 450 x 60 mm.

450 x 450 x 70 mm.

600 x 600 x 50 mm.

600 x 600 x 60 mm.

600 x 600 x 70 mm.

900 x 450 x 50 mm.

900 x 450 x 60 mm.

900 x 450 x 70 mm.

900 x 600 x 50 mm.

900 x 600 x 60 mm.

900 x 600 x 70 mm.

Finish

Flamed.

Performance requirements

-

Slip resistance

To BS 14231, 92 (dry); 73 (wet).

Manufacturer guidance

PTV.

Breaking load

To EN 12372, 15.9 MPa.

Guidance for specification option:

Lev = 15.1 MPa.

Water absorption (maximum)

To EN 13755, 0.3%.

Guidance for specification option:

Hev =0.3%.

Abrasion resistance

To EN 14157, 15.5 mm.

Guidance for specification option:

Hev = 16 mm.

Durability

To EN 12371, 15.9/ 14.7 MPa.

Manufacturer guidance

Freeze-thaw.

Material density

To EN 1936, 2630 k.g./m³.

Porosity

To EN 1936, 0.7%.

Manufacturer guidance

Open porosity.

CompressiveStrength

To EN 1926, 179 MPa.

Guidance for specification option:

Lev = 147 MPa.

Sustainability data

Country of material origin

Portugal
