Duct Panel Kits
Verified by manufacturer 24 days ago
Wall Panel System
Wall Panel System
Wall and panel lining systems for washrooms, cisterns and IPS.
Application
Suitable for commercial washrooms, cistern coverings, and healthcare wall integrated panelling applications.
Description
Duct panel kits are for commercial washrooms wall panels, toilet cistern boxing, and healthcare integrated panel systems.
Features and benefits:
- Full height panel system.
- Cistern panel system.
- IPS.
- Available in melamine faced chipboard (MFC) or compact grade laminate (CGL).
General information
Color | Beige Black Blue Bronze Brown |
Material | Laminate High pressure laminate (HPL) |
Shape | Rectangle |
Length | 800 mm |
Width | 20 mm |
Height | 3000 mm 1200 mm Bespoke |
Uniclass | |
CAWS | K32/140 Duct/ wall linings – panels only K32/150 Duct/ wall linings – panels and proprietary frames K32/15 Duct/ wall lining panels |
Specification data - Duct and wall panel lining systems
Panels | Melamine faced chipboard (MFC).Guidance for specification option: As standard. Compact grade laminate (CGL).High pressure laminate (HPL). |
Fasteners | Push fit panel clipsGuidance for specification option: As standard. Top-opening hinges.Side-opening hinges.Concealed cup hinges. |
Supporting frame | |
Duct panels | Guidance for specification option: Not included, timber supplied by another manufacturer. |
Edges | 2.0 mm PVC lipping (MFC or HPL only). Post-formed vertical edges (HPL only). Black, machine rounded profile (CGL only). |
Type | Washbasin. Urinal. WC. |
Height | Full height. Guidance for specification option: Bespoke to application up to 3000 mm, consult manufacturer and insert requirements. Half-height, sloping lid. Guidance for specification option: 1200 mm standard, consult manufacturer and insert requirements. |
Width | 800 mm. |
Thickness | 18 mm MFC. 20 mm HPL. |
Colour | Guidance for specification option: Consult manufacturer and insert requirements. |
Sustainability data
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Laminate High pressure laminate (HPL) |
Manufacturing plant location |
Literature
Healthcare IPS – Product Data Sheet
WallPanel Spec Cubicle Centre – Product Data Sheet
