Edilians Double HP20 - Clay roof tile

Verified by manufacturer 2 months ago

Edilians

Large, flat clay tile with the appearance of a small format interlocking tile and a thin, tapered leading edge.

Jump to:
+44 (0)7818 043810 Website

Application

Rooftile

Description

A large, flat clay interlocking tile, the Double HP20 has a thin, tapered leading edge. The slate colour tile can be specified as an economical natural alternative to man-made and other slates. This product whilst being large format has the appearance of a small module interlocking slate or tile coupled with low pitch suitability.


Dry fixing is recommended at ridges, hips and verges. A wide range of matching accessories is available to complete a traditional roof design, including ventilating tiles.


Features and benefits:

  • Distinctive natural colour range.
  • Large module for economical coverage 9.5 tiles per m².
  • Large tile for economical coverage.
  • Variable gauge for ease of installation.
  • Range of compatible fittings.
  • Complete dry roof solution available.
  • Natural product - silicone free.
  • Low pitch suitability: minimum pitch 17.5°.
  • Compatibility with Edilians PVt modules.
  • Comprehensive 30 year guarantee (subject to terms and conditions).
  • BS 6399-2:1997. BS 5534:2003 can be provided on request, contact Edilians for more details.

General information

Color

Red

Grey

Black

Brown

Bronze

Finish

Smooth

Material

Clay

Shape

Rectangle

Length

330 mm

Width

460 mm

Height

Bespoke

Warranty description

30 year

Uniclass

Pr_25_93_72_12 Clay interlocking tilesPrimary

CAWS

H65/105 Clay roof tiling

H65/110 Clay roof tiling with counterbattens

H65/3 Roof tiling

H65/5 Roof tiling

Specification data - Clay interlocking tiles

Standard

BS EN 1304.

Colour

Burnt Red (034).

Slate (011).

Vallée de Chevreuse (026).

Terre de Beauce (099).

Black Chevreuse.

Size

330 x 460 mm.

Width

420 mm.

Manufacturer guidance

(Effective width)

Capacity

9.5 per m².

Manufacturer guidance

(Covering capacity)

Gauge

225–250 mm.

Manufacturer guidance

(Nominal variable gauge)

Weight

4.3 kg per tile; 41 kg/m².

Roof pitch

17.5°.

Manufacturer guidance

(Minimum)

Battens

4.00 linear metres.

Manufacturer guidance

(Batten coverage m²)

Batten size

38 x 25 mm rafter centres 450 mm.

50 x 25 mm rafter centres 600 mm.

Staples/nails

50 x 3.35 mm.

Manufacturer guidance

(Nail size)

Sustainability data

Contains Red List materials

No

Country of material origin

France

Country of product manufacture

France

Material

Clay

Literature

Edilians Double HP20 Clay Roof Tile

Edilians Double HP20 Clay Roof Tile
