Verified by manufacturer 16 days ago
EPD
Certificate type
Certificate of Conformity
Certificate type
A range of heterogeneous sheet vinyl floor coverings in wood and stone designs which deliver 17 dB impact sound reduction.
Particularly suitable for use in areas where both impact and in room sound reduction is required such as libraries, schools, offices and communal areas.
A range of heterogeneous project vinyl coverings, with a high-density calendared top layer, with PUR Pearl™ guaranteeing easy maintenance and a long-lasting sheen and an additional acoustic foam backing that offers additional impact sound reduction of 17 dB.
Features and benefits:
Color | Brown Beige Grey Silver Black Manufacturer guidanceAvailable in 22 colourways (13 wood designs and 9 concrete, tile and metal effects). |
Finish | Lacquered |
Material | PVC |
Shape | Rectangle |
Length | 2500 mm |
Width | 2000 mm 4000 mm |
Height | 2 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | M50/20 Sheeting M50/150 Sheeting |
Product range |
Standard | To EN ISO 10582. |
Use class | Class 23 / 34 / 43. |
Slip potential | |
Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum) | DIN 51130, R10; BS EN 13893, DS ≥0.30. |
Width | 2000 mm.4000 mm. |
Thickness | 3.0 mm. |
Colour and pattern | 3052 golden oak.3045 natural oak.3024 grey pine.3018 whitewashed oak.3016 light honey oak.3112 mid neutral grey.3111 light neutral grey.3073 blond large herringbone.3074 classic large herringbone.3092 bleached elegant oak.3093 warm elegant oak.3094 dark elegant oak.3010 warm honey oak.3005 multisize light oak.3006 multisize hazelnut oak.3048 pale oak.3117 white neutral grey.3066 mortar concrete.3067 graphite concrete.3068 warm concrete. |
Weight | 2550 g/m². |
Dimension stability (to EN-ISO 23999) | <0.1%. |
UKSRG pendulum test | PTV dry>50. |
Resistance to chemicals (to EN-ISO 26787) | Very good. |
Lightfastness (to ISO 105-B02) | ≥6. |
Indoor Air Emissions (to ISO 16516) | TVOC after 28 days: <50 μg/m³. |
CE Marked to EN 14041 | Meets requirements. |
Reaction to fire (to BS EN 13501) | BfI-s1, L, NCS. |
Body voltage (to BS EN 1815) | <2 kV. |
Thermal conductivity (to BS EN 12524) | 0.25 W/m. |
Wear layer | 0.7 mm. |
Edging | Not required. As per 740. |
Skirtings | Not required. As per 770. |
Stair nosings | Not required. As per 750. |
Contains Red List materials | Yes |
Country of material origin | Netherlands |
Country of product manufacture | Netherlands |
Material | PVC |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 4.54 kg CO₂ eq/m² |
Recyclability | Yes Guidance for specification option: Via Forbo's Back to the Floor scheme |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 30.5 % Guidance for specification option: Eternal contains up to 70% recycled content in the backing |
