Fastwarm® Loose Cable System
Verified by manufacturer 2 months ago
Length: 104 m/ Area Coverage: 5.20–10.40 m²
Length: 104 m/ Area Coverage: 5.20–10.40 m²
Electric underfloor heating cables.
Application
- Underfloor heating cable compatible with any shaped floor space with the mats designed for a quick and easy installation due to its versatility.
- Suitable for use in wet areas.
Description
FastWarm heating cables are comprised of thin (2 mm) fluoropolymer (Teflon) coated, dual-core resistive heating cable. The cables can be spaced at an appropriate distance to provide an even heat distribution across the floor to suit the required heat output. The cable system allows for use in small confined areas (bathrooms and en suites) plus complicated shaped areas, making fitting a FastWarm underfloor heating cable easy to install.
Features and benefits:
- 2 mm thick cable complies to IEC 60335 standards and is also UKCA approved.
- Evenly spaced Fluropolymer dual core heating elements which ensure consistent desired heat output.
- Combining the highest comfort level with maximum energy efficiency.
- Single point connection.
- No PVC used on heating element.
- Suitable for wet areas IPx7.
- Emits zero EMF (electromagnetic fields).
- Flexible and durable constructed cable.
General information
Color | Red Black |
Finish | Coated |
Material | Polymer Guidance for specification option: Multi strand twin core conductor, fluoropolymer insulation (Teflon), earth braid, fluoropolymer insulation (Teflon). |
Shape | Other |
Length | 11500 mm 14000 mm 17000 mm 22500 mm 29000 mm |
Width | 2 mm |
Warranty description | Lifetime |
Uniclass | |
CAWS | T90/478 Underfloor electric heating cables |
Specification data - Electric cable underfloor heating elements
Standards | To BS EN 60335-1 and BS EN 60335-2-96. |
Rating | 10 W/m. |
Accessories | Not required.Digital thermostat.Touch black thermostat.Touch white thermostat.WiFi black thermostat.WiFi white thermostat.Fastwarm Fastprime primer. |
Spacing | 100 W at 100 mm. 150 W at 65 mm. 200 W at 50 mm. Manufacturer guidanceCable spacing. |
Cable | ⌀2 mm. |
Voltage | 230 V. |
Length | 104 m. |
TotalWattage | 1040 W. |
Resistance | 50.9 0hms. |
Area | 5.20–10.40 m². |
Sustainability data
Material | Polymer Guidance for specification option: Multi strand twin core conductor, fluoropolymer insulation (Teflon), earth braid, fluoropolymer insulation (Teflon). |
Literature
Cable Spacing Guide
Fastwarm Loose Cable Install Manual
