Grosvenor Deck Mounted Bath Filler

Verified by manufacturer 17 days ago

Chrome Finish – 76223

JTP UK Variant:

Bath mixer tap.

Jump to:
+44 1895 442211 Website

Application

Suitable for deck mounting on baths.

Description

Grosvenor Deck Mounted Bath Filler is a mixer taps for baths with a selection of finishes.


Features and benefits:

  • Deck-mounted.
  • Multiple finish options.

General information

Color

Black

Bronze

Gold

Silver

Copper

Finish

Brushed

Chrome

Antiqued

Material

Brass

Shape

Other

Length

180 mm

Width

162 mm

Height

162 mm

Warranty description

Five year

Guidance for specification option:

Cartridges warranty period.

15 year

Guidance for specification option:

Product warranty period.

Uniclass

Pr_40_20_87_08 Bath mixer tapsPrimary

CAWS

N13/35 Baths

N13/355 Baths

Specification data - Bath mixer taps

Form

Bath mixer tap.

Materials

-

Body

Brass.

Finish and colour

Chrome-plated.

Flow rate (maximum)

20.2 L/min at 3 bar.

Guidance for specification option:

Maximum flow rate at other pressures:

  • 17 L/min at 2 bar.
  • 12.5 L/min at 1 bar.
  • 10.5 L/min at 0.5 bar.
  • 9L/min at 0.2 bar.

Water supply temperature (maximum)

User-controlled.

Connection

G¾".

Sustainability data

Contains Red List materials

No

Country of material origin

China

Country of product manufacture

China

Material

Brass

Recyclability

100%

Literature

Grosvenor Deck Mounted Bath Filler – Product Data Sheet

Grosvenor Deck Mounted Bath Filler – Product Data Sheet
