Hafele Optimo Sliding Pocket Door System

Not required.

Self close up to 90 kg.

Guidance for specification option:

The kit contains two different weights so that the self close can be adjusted to 45 or 90 kg depending on the weight of the door.

Soft close.

Guidance for specification option:

Provides a soft closing and opening of the door. It retains the door in the last 100 mm of its sliding path, holding it in a controlled way until the end of its journey and avoiding slams as well as extending the useful life of the product.

OPTIMO jamb kit non fire rated (100 mm FW).

Guidance for specification option:

• The jamb kit includes white weather strips and rubber gaskets.
• Natural finger-jointed wood finish.
• For finished wall thickness 100 mm.

OPTIMO jamb kit non fire rated (125 mm FW).

Guidance for specification option:

• The jamb kit includes white weather strips and rubber gaskets.
• Natural finger-jointed wood finish.
• For finished wall thickness 125 mm.

OPTIMO jamb kit FD30 (125 mm FW).

Guidance for specification option:

• MDF fire rated jamb kit for single FD30 rated doors.
• Fully certified to EN 1634-1:2016+A1:2018 for fire resistance.
• Only for use with 44 mm thick FD30 timber doors (not supplied).
• Available for finished wall thickness 125 mm.
• Intumescent strips included.
• Use two layers of 12.5 mm fireboard each side (not supplied)

100 mm.

125 mm.

No

Spain

Spain

Aluminium

Yes
