Heavy, Severe Duty Non-Fire Rated Doors

Verified by manufacturer 3 months ago

Bridgman IBC Ltd

Doors for heavy duty use in non fire-resisting applications.

Jump to:
+44 (0)1429 221111 Website

Application

Suitable for heavy duty use in non fire-resisting applications.

Description

Doors for heavy duty use in non fire-resisting applications.


Features and benefits:

  • Constructed from a solid laminate timber core, available in 44 mm and 54 mm thickness.
  • Available with FSC/ PEFC certification - consult manufacturer for details.
  • Bridgman are members of the Exova/ BM Trada Q Mark Scheme.

General information

Shape

Rectangle

Finish

Primed

Guidance for specification option:

Factory primed.

Laminated

Lacquered

Manufacturer guidance

Also available with a Hygienilac finish.

Material

Wood

Warranty description

25 year

Guidance for specification option:

Royd and Tucker Hi-Load H105 lift off hinges with 25 year guarantee.

Uniclass

Pr_30_59_23_97 Wood flush door leavesPrimary

CAWS

L20/20 Wood flush doors

L20/230 Wood flush doors

Specification data - Wood flush door leaves

Format

Single leaf, single action.

Thickness

44 mm.

54 mm.

Facings

Acovyn.

Laminated.

Medium density fibreboard (MDF).

Plywood.

Veneered.

Lippings

Hardwood.

Finish

Factory primed.

Hygienilac.

Laminated.

Lacquered.

Accessories

Not required.

Kick plates.

Guidance for specification option:

Consult manufacturer for details.

Mouldings.

Guidance for specification option:

Consult manufacturer for details.

Overpanels.

Guidance for specification option:

Consult manufacturer for details.

Push plates.

Guidance for specification option:

Consult manufacturer for details.

Factory mortising for locks.

Guidance for specification option:

Consult manufacturer for details.

Slots for letter plates.

Guidance for specification option:

Consult manufacturer for details.

Water bar rebates.

Guidance for specification option:

Consult manufacturer for details.

Core

Timber.

Planted stops

Hardwood.

Softwood.

Type

Solid rebated frame with integral stop.

Guidance for specification option:

Main section 94 x 44 mm (finished). Extensions can be fitted for wall depths up to 200 mm.

Planed square edge (PSE) section with loose door stops.

Guidance for specification option:

32 mm up to 125 mm solid (one piece) with a 32 x 13 mm stop. For wall depths in excess of 125 mm a tongued extension piece is fitted.

Manufacturer guidance

Door frame type.
