HELIA - Solar Lighting Bollard

Verified by manufacturer 4 months ago

SolarVision Lighting Technologies Third party certifications:
  • Health & Safety Accreditation

    Health & Safety Accreditation

    Certificate type

  • Constructionline Gold

    Constructionline Gold

    Certificate type

  • Acclaim Accreditation

    Certificate type

  • Corporate Group Member

    Certificate type

Solar powered aluminium lighting bollard. LED, contemporary traffic and security bollard. Programmable lighting and removable. Ideal of paths and walkways.

Jump to:
+44 01923 726150 Website

Application

Designed for multi purpose installations. Suitable for both commercial and residential sites.

Description

Helia Solar Lighting Bollard is designed to provide a subtle and much needed option to light areas where street light would be over baring. Suitable for access roads and footpaths to parks, clubs, country estates, car parks and cycle routes.


The lighting bollard is equipped with advanced LED and photovoltaic technology. The vertical design of the SOLAR WRAP® provides for very low maintenance, reducing the need for cleaning, which maximizes yields at all times.


Once installed the unit immediately charges the

battery and manages a lighting profile specific to the

clients requirements. With a built-in dusk to dawn sensor and a motion sensor, SolarVision Lighting are able to provide a working solution for all seasons and reduce the light pollution during the night to protect habitat in the surrounding area.


Features and benefits:

  • Height: 1.3 m.
  • LED power: 5 w.
  • Battery capacity: 230 wh.
  • Battery autonomy: >3 days.
  • Motion sensor: PIR.
  • Lifetime: >25 years.

General information

Color

Black

Finish

Painted

Material

Aluminium

Shape

Other

Length

Bespoke

Width

226 mm

Height

1350 mm

Warranty description

Three year

Uniclass

Pr_80_77_48_02 Aluminium lighting bollardsPrimary

CAWS

V91/340 Luminaires for road and street lighting

Q50/31 Bollards

Q50/190 Bollards

Product range

Solar Bollards

Specification data - Aluminium lighting bollards

Profile

Parallel-sided and stepped.

Cross section

Square.

Height (nominal)

1350 mm.

Base

-

Type

Bolted flange.

Bollard diameter

140 mm.

Corrosion protection

-

Type

Painted.

Colour

Black.

Guidance for specification option:

Jet black (RAL9005).


Light source

-

Head

Powder-coated, die-cast aluminium.

Lamp type and rating

5 W.

Manufacturer guidance

LED rated power.

Ingress protection (minimum)

IP65.

Luminous flux

600 lm.

Colour temperature

4000 k.

Sensor

PIR.

Working temperature

-15ºC to 70ºC.

Battery

Lithium Iron Phosphate - LiFeP04 (2000 Cycles).

Guidance for specification option:

  • Battery lifetime: >4000 cycles DOD 50% or >2000 cycles at 100% DOD.
  • Battery autonomy: 2–3 days.

Solar system

Q55.

Guidance for specification option:

  • Dimensions: 228 x 200 x 600 mm.
  • Pmax: 55 wp.
  • Solar cell efficiency: 20.20%.
  • Operating temperature: -30ºC to 70ºC.

Controller

Programmable MPPT controller.

Guidance for specification option:

  • Charge mode: MPPT.
  • System voltage: 12 V.
  • Efficiency: >98%.
  • Setting method: remote control.
  • Installation method: built-in.
  • Operating temperature: -40ºC to 80ºC.
  • IP rating: IP68.

Sustainability data

Contains Red List materials

No

Country of material origin

China

Country of product manufacture

United Kingdom

Material

Aluminium

Manufacturing plant location

Recyclability

Aluminum post, components in the battery and the PV wrap are all recyclable as they can be broken down into their original materials such as glass, aluminum, silicon, zinc, manganese, potassium, cobalt, nickel and lithium

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

80 %

Expected Life

25 year

Third party certifications

Health & Safety Accreditation

Health & Safety Accreditation

Acclaim Accreditation Certificate

Constructionline Gold

Constructionline Gold

Construction Line Gold Member

 Acclaim Accreditation

Acclaim Accreditation

Acclaim Accreditation DTS Certificate

Corporate Group Member

Corporate Group Member

ILP Corporate Group Member
