High Acoustic Glazing - Glazed Relocatable Partitions

Verified by manufacturer 2 months ago

Lusso 205dB

Lusso Systems Ltd Variant:

Acoustic glazed partitions with minimal perimeter framework, acoustically tested to achieve up to 60 dB.

Jump to:
BOS
01275 372293 Website

Application

For use in a range of applications and sectors. These include commercial, education, healthcare, leisure, automotive, retail and technology.

Description

Acoustic glazed partitions with minimal perimeter framework, acoustically tested to achieve up to 60 dB.


The L205dB double-glazed partitions are acoustically tested in full UKAS facilities to achieve up to 57 dB, and the L305dB triple-glazed partitions are acoustically tested to achieve up to 60 dB.


Both partitions provide all the aesthetic benefits of the standard 105 system, with added acoustic performance.


Features and benefits:

  • Minimalistic powder-coated aluminium framework, in a variety of RAL colours and finishes.
  • Glass thicknesses from 6–17 mm.
  • High acoustic performance up to 60 dB.


Please note that acoustic, fire-rated and structural certification and support for Lusso products and systems is available on a project-specific basis. Please contact Lusso's specification team directly for further information.

General information

Color

Other

Guidance for specification option:

RAL polyester powder-coated or anodized.

Finish

Powder-coated

Polished

Guidance for specification option:

Chemically brightened.

Anodized

Material

Glass

Aluminium

Shape

Rectangle

Length

Bespoke

Guidance for specification option:

Please consult manufacturer for further details.

Width

Bespoke

Guidance for specification option:

Please consult manufacturer for further details.

Height

Bespoke

Guidance for specification option:

Please consult manufacturer for further details.

Warranty description

-

Manufacturer guidance

Based on a job specific basis, please contact Lusso for further information.

Uniclass

Pr_25_71_57_60 Partition panelsPrimary

CAWS

K30/10 Relocatable partition system

K30/130 Relocatable partition system

Specification data - Partition panels

Third-party certification

Constructionline-Gold; Builders Profile; CHAS; FIRAS; SMAS; Acclaim (SIPP).

Unit size

-

Thickness

Up to 220 mm.

Partition height (nominal)

-

Manufacturer guidance

Consult with manufacturer for details.

Width (nominal)

-

Manufacturer guidance

Consult with manufacturer for details.

Deflection allowance (maximum)

-

Head

28 mm deep x 24 mm wide with clip-on-bead.

28 mm deep x 30 mm wide with clip-on-bead.

Manufacturer guidance

To suit 6-17 mm glass.

Floor

28 mm deep x 24 mm wide with clip-on-bead.

28 mm deep x 30 mm wide with clip-on-bead.

Manufacturer guidance

To suit 6-17 mm glass.

Verticals

28 mm deep x 24 mm wide with clip-on-bead.

28 mm deep x 30 mm wide with clip-on-bead.

Manufacturer guidance

To suit 6–17 mm glass.

Panel partition type

Framed relocatable partition.

Framing, fixing points and joints

Aluminium extruded sections.

Guidance for specification option:

Fixings as per manufacturer literature.

Glazed panels

-

Type

Double-glazed, 10.8–16.8 mm acoustic laminate safety glass.

Double-glazed, 6–15 mm toughened safety glass.

Double-glazed, 6–15 mm heat-soaked toughened safety glass.

Double-glazed, 6–15 mm switchable smart glass.

Manufacturer guidance

All glass types available; please consult Lusso with all requirements.

Cable management and outlets

Not required.

Double glazed Tech Panel to accommodate access control and other electronics.

Manifestation

None.

2 rows of 50 mm opal frost dots.

2 rows of 50 mm opal frost squares.

Privacy mirror film.

Client specific custom designs.

Guidance for specification option:

Insert requirements.

Acoustic performance

52 dB (Rw).

54 dB (Rw).

56 dB (Rw).

57 dB (Rw).

Manufacturer guidance

Ratings in accordance with BS EN ISO 717-1: 1997 and tested to BS EN ISO 140-3:1995.

Fasteners

To manufacturer’s specifications.

Samples required

-

Manufacturer guidance

Available from manufacturer on request.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recyclability

100% (Aluminium and glass)

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

80 %

Manufacturer guidance

Glass % available from manufacturer on request.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
