Hudevad Novus - Radiator Bench

Verified by manufacturer 5 months ago

Type 70 Radiator Bench

Hudevad Radiator Design A/S Variant:

Floor-mounted bench radiator with integrated legs.

Jump to:
+44 (0)24 7688 1200 Website

Application

Suitable for use in many public spaces, such as hospitals, schools and offices as well as private homes.

Description

The Novus Bench radiator is suitable for use in many public spaces, such as hospitals, schools and offices as well as private homes. Its symmetrical lines and functional shapes without convectors make cleaning easy.


Placed in front of windows, Novus is suitable as protection against cold drafts.


Features and benefits:

  • Pre-treatment by degreasing and steel phosphating in accordance with DIN EN 442 and DIN EN 12476.
  • Powder coated in accordance with DIN 55900, EN 442.
  • Max operating pressure 6 bar according to EN 442.
  • Panels: profiled steel tubes 70 x 11 x 1.8 mm.
  • Distance between panels are 20 mm.

General information

Color

White

Guidance for specification option:

White RAL 9016 70% Gloss.

Other

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Length

1000 mm

1100 mm

1200 mm

1400 mm

1500 mm

Show more

Width

197 mm

259 mm

321 mm

Height

190 mm

400 mm

Warranty description

Ten year

Uniclass

Pr_70_60_36_73 RadiatorsPrimary
Pr_40_30_29_84 Street and site benches

CAWS

T90/465 Radiators

Q50/220 Benches

T90/465 Radiators

Q50/33 Benches

Specification data - Radiators

Standards

To BS EN 442-1 and BS EN 442-2.

Radiator type

Bench.

Output

Guidance for specification option:

Consult manufacturer and insert requirements.

Finish

Powder-coated.

Guidance for specification option:

 In accordance with DIN 55900, EN 442.

Connections

Guidance for specification option:

Consult manufacturer and insert requirements.

Manufacturer guidance

All connections 1/2” standard.

Accessories

Not required.

Leather cushions.

Guidance for specification option:

L: 420 x W: 270 x H: 10 mm. In the colours cognac, dark brown and black.

Panels

Profiled steel tubes.

Guidance for specification option:

70 x 11 x 1.8 mm.

Panels

Seven.

Colour

White RAL 9016, gloss 70.

Guidance for specification option:

Standard.

Other.

Guidance for specification option:

Can be painted in other colours. Insert requirements.

TestPressure

8 bar.

Operating pressure (maximum)

6 bar.

Operating temperature

110°C.

Height

190 mm.

400 mm.

Depth

197 mm.

Length

1000 mm.

1100 mm.

1200 mm.

1400 mm.

1500 mm.

Show more

Tapping configuration

Type code 50.

Guidance for specification option:

Tapping type: E/F, no valve.

Type code 52.

Guidance for specification option:

Tapping type: FF, right.

Type code 53.

Guidance for specification option:

Tapping type: EE, left.

Sustainability data

Contains Red List materials

No

Country of material origin

Italy

Country of product manufacture

Latvia

Recyclability

Yes

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Hudevad Novus

Hudevad Novus
