Hudevad Plan XV - Vertical Radiator

Name: Hudevad Plan XV - Vertical Radiator
Brand: Hudevad Radiator Design A/S
SKU: gBMytRWtGXE6ADTE4virBL

Verified by manufacturer 17 days ago

Type 11 Radiator

Hudevad Radiator Design A/S

Third party certifications:

Independent sustainability assessment
Certificate type

Wall mounted radiator in steel with fixed casing and convectors.

Jump to:

+44 (0)24 7688 1200 Website

Application

Suitable choice for large halls or areas that are difficult to heat.

Description

Hudevad Plan XV Vertical is made with several radiators inside and finishes with a simple and smooth cover made from 2 mm steel with defined corners. The Plan XV Vertical is suitable for installation and adaptation to challenging locations, where there is a need to hide the radiator or highlight it so that it can become an active part of the decoration. The radiator has high outputs and functionality, which makes it a suitable choice for large halls or areas that are difficult to heat.

Features and benefits:

Pre-treatment by alkaline degreasing and a layer of zirconia as conversion coating.
Powder coated in accordance with DIN 55900, EN 442.
Max operating pressure 10 bar in accordance with EN 442.
2 mm steel casing according to EN 10051.
Steel panel (heating element) according to EN 442.

General information

Color	White Guidance for specification option: White RAL 9016 70% Gloss. Other
Finish	Powder-coated
Material	Steel
Shape	Rectangle
Length	550 mm 650 mm 750 mm 850 mm 950 mm 1050 mm 1150 mm Show more
Width	91 mm 116 mm 173 mm 67 mm
Height	2000 mm 2200 mm 2400 mm 2500 mm 2600 mm 2800 mm 3000 mm Show more Manufacturer guidance The frontplate is 188 mm higher than the underlying emitters.
Warranty description	Ten year

Uniclass	Pr_70_60_36_73 RadiatorsPrimary
CAWS	T90/465 Radiators T90/465 Radiators

Specification data - Radiators

Standards	To BS EN 442-1 and BS EN 442-2.
Radiator type	Single panel single convector. Guidance for specification option: Type 21.
Output	Guidance for specification option: Consult manufacturer and insert requirements.
Finish	Powder-coated. Guidance for specification option: In accordance with DIN 55900, EN 442.
Connections	Guidance for specification option: Consult manufacturer and insert requirements. Manufacturer guidance All connections 1/2” standard (adapters available).
Accessories	Guidance for specification option: Hudevad recommends use of Danfoss accessories when fitting the radiator. For further accessories please refer to the Hudevad Pricelist.

Casing	To EN 10051, 2.00 mm steel.
Heating element	To EN 442, steel panel.
Colour	White RAL 9016, gloss 70. Guidance for specification option: Standard. Other. Guidance for specification option: Can be painted in other colours. Insert requirements.
TestPressure	13 bar.
Operating pressure (maximum)	To EN 442, 10 bar.
Operating temperature	95°C.
Height	2000 mm. Guidance for specification option: H1: 2000 mm. H2: 500 mm. H3: 500 mm. H4: 700 mm. 2200 mm. Guidance for specification option: H1: 2200 mm. H2: 600 mm. H3: 600 mm. H4: 700 mm. 2400 mm. Guidance for specification option: H1: 2400 mm. H2: 700 mm. H3: 700 mm. H4: 700 mm. 2500 mm. Guidance for specification option: H1: 2500 mm. H2: 600 mm. H3: 700 mm. H4: 900 mm. 2600 mm. Guidance for specification option: H1: 2600 mm. H2: 700 mm. H3: 700 mm. H4: 900 mm. 2800 mm. Guidance for specification option: H1: 2800 mm. H2: 700 mm. H3: 900 mm. H4: 900 mm. 3000 mm. Guidance for specification option: H1: 3000 mm. H2: 900 mm. H3: 900 mm. H4: 900 mm. Show more Manufacturer guidance The frontplate is 188 mm higher than the underlying emitters.
Depth	79 mm.
Length	550 mm. Guidance for specification option: L1: 550 mm. L2: 400 mm. L3: 438 mm. 650 mm. Guidance for specification option: L1: 650 mm. L2: 500 mm. L3: 538 mm. 750 mm. Guidance for specification option: L1: 750 mm. L2: 600 mm. L3: 638 mm. 850 mm. Guidance for specification option: L1: 850 mm. L2: 700 mm. L3: 738 mm. 950 mm. Guidance for specification option: L1: 950 mm. L2: 800 mm. L3: 838 mm. 1050 mm. Guidance for specification option: L1: 1050 mm. L2: 900 mm. L3: 938 mm. 1150 mm. Guidance for specification option: L1: 1150 mm. L2: 1000 mm. L3: 1038 mm. Show more
Tapping configuration	Tapping code 27. Guidance for specification option: Tapping type: E/F, no valve, flow left. Tapping code 28. Guidance for specification option: Tapping type: E/F, no valve, flow right. Tapping code 29. Guidance for specification option: Tapping type: G/H top tap, no valve, flow left. Tapping code 30. Guidance for specification option: Tapping type: G/H top tap, no valve, flow right. Manufacturer guidance See manufacturers literature for further information.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	Denmark
Recyclability	Yes
Recycled content As defined in clause 7.8 of BS EN ISO 14021	99 %
