Verified by manufacturer 5 months ago
HC45T128
EPD
Certificate type
Under-counter chilled and ambient water dispenser.
For a range of applications.
HydroChill HC45 under counter chilled water dispensing with heavy-duty tap and 3 micron, Zip MicroPurity filtration. With a capacity of 28 litres per hour, and the capability for one-touch filling of bottles and carafes.
Features and benefits:
Color | Black |
Finish | Polished |
Material | Brass Guidance for specification option: Chrome plated. |
Length | 343 mm |
Width | 181 mm |
Height | 378 mm |
Warranty description | One year Guidance for specification option: One year on site parts and labour warranty. |
Uniclass | |
CAWS | N12/340 Appliances N12/340 Appliances N11/40 Appliances N13/379 Drinking fountains |
Product range |
Arrangement | Filtered chilled water dispenser.Filtered chilled and ambient water dispenser. |
Flow rate | 28 L/h. |
Temperature of delivered water | 5–12°C. |
Water inlet | 1/2" BSP. |
Power supply | 0.33 kW at 230 V.Guidance for specification option: 1 x 13 A socket outlet. |
Font | Not required. Required. |
Type | Chilled. |
Contains Red List materials | No |
Country of material origin | Australia |
Country of product manufacture | Australia |
Certified
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
