HydroTap G5 Celsius Plus All in One

Verified by manufacturer 2 months ago

Boiling, Chilled and Sparkling - BCS H&C for Home

Zip Water Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

  • WRAS

    WRAS

    Certificate type

Drinking water system providing instant, filtered boiling, chilled and sparkling drinking water.

Jump to:
BOS
+44 (0)345 6 005 005 Website

Application

Suitable for residential and commercial applications.

Description

Drinking water systems for the home, the all-in-one system delivers instant, pure-tasting filtered boiling, chilled and sparkling drinking water, operated via a touchpad hand.


Features and benefits:

  • Advanced filtration.
  • Maintains existing protective levels of chlorine whilst removing sediment and cysts. This level of filtration includes the removal of dirt, lead, microplastics and 99.9% of microbiological cysts.
  • Environmentally conscious operation.
  • Range of eco-friendly functionalities, including water conserving air cooling technology, the use of zero-impact refrigerant gas R290 and energy saving sleep modes.
  • User safety options - designed with safety in mind, with boiling isolation, cool touch tap and safety lock features. The boiling point is factory set to 98℃, to avoid spluttering steam.
  • Enhanced hygiene.
  • SteriTouch® embedded throughout the water path, this reduces surface bacteria by 99.99% providing extra protection.

General information

Color

Silver

Black

Pink

Gold

Grey

Finish

Bright

Brushed

Matt

Material

Stainless steel

Polymer

Guidance for specification option:

Polyphenylene sulfide (PPS).

Shape

Other

Length

271 mm

Manufacturer guidance

Tap projection.

Width

60 mm

Manufacturer guidance

Tap base width.

Height

440 mm

Manufacturer guidance

Tap height.

Warranty description

Five year

Uniclass

Pr_40_70_23_42 Instant boiling and cold water tapsPrimary

CAWS

N11/30 Sinks, taps, traps and wastes

N11/350 Sinks, taps, traps and wastes

N12/380 Sinks, taps, traps and wastes

N12/380 Sinks, taps, traps and wastes

Specification data - Instant boiling and cold water taps

Third-party certification

UKCA and CE marked.

Water

Boiling, chilled and sparkling.

Duty

-

Dimensions

339 x 483 x 333 mm.

Electrical connection

-

Power

1.7 kW.

Voltage

230 V.

Water inlet

1 x isolated 1/2"BSP BSP fitting (flexible supply hoses included).

Manufacturer guidance

Supply connection (hot and cold).

Safety features

Touch control.

Taps

Celsius Plus AIO.

Guidance for specification option:

  • Installation hole cut size: 50 mm.
  • Rotation: 180°.
  • Disability options: no.
  • Tap height: 440 mm.
  • Tap projection: 271 mm.

Finish and colour

H5M783Z00UK - Bright chrome.

H5M783Z01UK - Brushed chrome.

H5M783Z03UK - Matt black.

H5M783Z05UK - Brushed rose gold.

H5M783Z07UK - Brushed gold.

Show more

Hot water supply temperature

Factory temperature boiling: 98°C.
Factory temperature chilled: 3–5°C.

Filtration

0.2 µm filter cartridge.

Flow rate

Boiling: 4 L/min.
Chilled: 4 L/min.
Sparkling: 1.6 L/min.

Refrigerant

R290.

Accessories

Not required.

CO2 Replacement cylinders 2 x 1.2 kg.

Guidance for specification option:

SKU: 91295.

Zip limescale prevention filter for home.

Guidance for specification option:

SKU: 95601.

Pair of 3/8" PF equal elbows for limescale filter 95601 and 95602.

Guidance for specification option:

SKU: 95584.

Zip HydroTap G4 and G5 limescale filter kit for home.

Guidance for specification option:

SKU: 95591.

Sustainability data

Contains Red List materials

No

Country of material origin

Australia

Country of product manufacture

Australia

Material

Stainless steel

Polymer

Guidance for specification option:

Polyphenylene sulfide (PPS).

Third party certifications

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Third party certifications

EPD

EPD

Environmental Product Declaration

WRAS

WRAS

WRAS Approval: Celsius Plus All-in-One
