Isocrete Isogran Screed
Verified by manufacturer over a year ago
Concrete (granolithic) wearing screed mixes.
Application
Suitable for store rooms, workshops, plant rooms, service areas in offices, hospitals, laundries, etc. It can be used as a base for resin finishes.
IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.
Description
A polymer modified granolithic wearing screed used in conjunction with heavy-duty industrial and commercial flooring systems. The product provides wear resistant, heavy duty flooring.
Features and benefits:
- Heavy duty wearing screed.
- Resistant to impact damage and surface wear.
- Resistant to oil, petrol and grease.
- Maintenance free apart from normal sweeping and washing.
General information
Finish | Trowelled |
Material | Cement |
Warranty description | Ten year |
Uniclass | |
CAWS | M10/17 Proprietary polymer modified wearing screeds M10/185 Proprietary polymer modified wearing screeds |
Specification data - Granolithic concrete wearing screed mixes
Cement | Portland Cement CEM 1. |
Coarse aggregate | 5 mm Clean granite. |
Fine aggregate | Sharp sand. |
Mix | 1:03. |
Bay size | 15 m², 5 m maximum length. |
CompressiveStrength | >55 N/mm². |
Cure time | Light traffic: 3-4 days, Full traffic: 10-14 days, Curing under polythene: 5 days. |
Density | 2150–2250 kg/m³. |
Minimum thickness | Bonded (single layer): 20–50 mm. Bonded (two layers): 50–80 mm. Bonded stair treads: 25 mm. Bonded stair risers: 20–30 mm. |
Thickness range | 20–80 mm. |
Uses | Heavy duty flooring on in-situ concrete decks for store rooms, workshops, plant rooms, service areas in offices, hospitals and laundries, etc. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 3 |
 IFC | - | 2 |
