Kestrel Aluminium Inline Sliding Patio Door System - Aluminium door sliding system
Verified by manufacturer 7 months ago
Inline Sliding
Inline Sliding
Sliding patio door system.
Application
Residential new build, refurbishment and light commercial.
Description
Innovative and practical, the Sliding Patio Door System
provides an alternative to a set of French or folding
sliding doors.
The minimal sightlines create a dramatic removable
wall that provides uninterrupted views to the outdoors.
Whilst a thermally efficient, security tested door system
provides peace of mind that the home is safe and secure.
Features and benefits:
- Double track sliding door.
- Single and dual colour powder coated.
- Double and triple glazed.
- 106 mm interlock.
- 111 mm outer jamb.
- 33 mm low threshold.
- Soft brake close option.
- Integral trickle vents.
- Low line gaskets.
- PAS24 compliant.
General information
Finish | Powder-coated Anodized Mill |
Material | Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke Manufacturer guidanceMaximum door leaf width: 2000 mm. |
Height | Bespoke Manufacturer guidanceMaximum door leaf height: 2300 mm. |
Warranty description | Ten year |
Uniclass | |
CAWS | L20/520 Sliding doors L20/55 Doorsets L20/60 Doors |
Specification data - Sliding door and partition sets
Classification data | |
Arrangement | Inline sliding. |
Door leaves | |
Construction | Aluminium. |
Finish and colour | Mill finish. Etched and anodized Silver AA25. Guidance for specification option: other colours on request. Polyester powder coated. Guidance for specification option: See separate list for standard colour range available. |
Operation | Manual. |
Accessories | Soft brake close. |
Colour: | Manufacturer guidanceSingle and dual colour powder coated options available, consult manufacturer for details and insert requirements. |
Glazing | Guidance for specification option: Will accept double or triple IGU and infill panels 28 - 42 mm thick. |
Jointing | Mechanical. |
Beading | Internal. |
U-value | 1.6 W/m²K. |
Standards | BS EN 12020-2, BS 3987, BS EN 12206-1, BS 4873, BS EN 14351-1, BS EN ISO 10077-2, PAS 24. |
Size (w x h) | 2000 x 2300 mm. |
Weight | 200 kg. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/kg) Stage:A1–A3 ('Production stage') Normalised unit : 4 (kg CO₂ eq/kg) Declared unit : 4.0 | |
Recyclability | Aluminium building products are collected and recycled at end-of-life very efficiently, and the end-of-life recycling rate for aluminium is >90%. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 79 % |
Literature
Literature type
Datasheet Kestrel Systems Technical Specifications
Datasheet Kestrel Patio Sliding Door System
