Kestrel Aluminium Residential Door System (Single Leaf) - Aluminium Door System

Verified by manufacturer 5 months ago

Kestrel Aluminium Systems

Aluminium residential door.

Jump to:
+44 (0)1213333575 Website

Application

Residential new build, refurbishment and light commercial.

Description

The Kestrel Thermal Rebate Door is designed for

residential and light commercial use. The suite of profiles

will allow construction of single and double door types.

The system is internally beaded as default. An externally

beaded door leaf could be constructed if required by

simply reversing the stiles/rails.


Designed as part of a residential suite of products the

rebate door system utilizes the same profiles to offer

commonality of design. Fixed sidelights or fan lights can be

incorporated into the design offering the option for

increased ventilation and natural light. The system is suitable for use as either an entrance door to the home or as French doors leading to the garden. Doors can be single or double, opening in or out, to meet the project specification.


Features and benefits:

  • Single or dual colour.
  • Open in or out.
  • Single or double doors.
  • Threshold and cill options.
  • Midrail options.
  • Hardware to mirror Folding Sliding Door.

General information

Finish

Anodized

Mill

Powder-coated

Material

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Manufacturer guidance

Maximum door width: 1000 mm.


Height

Bespoke

Manufacturer guidance

Maximum door height: 2700 mm.


Warranty description

Ten year

Uniclass

Pr_30_59_24_02 Aluminium doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Aluminium doorsets

Standard

BS EN 12020-2, BS 3987, BS EN 12206-1, BS 4873, BS EN 14351-1, BS EN ISO 10077-2, PAS 24.

Configuration

Single leaf, open out.

Single leaf, open in.

Doorset size

-

Manufacturer guidance

Maximum door width: 1000 mm.

Maximum door height: 2700 mm.

Performance

-

Thermal

Thermal transmittance: 1.6 W/m²K.

Frame

-

Material

Aluminium.

Finish

-

Coating

Polyester powder coated.

Mill finish.

Etched and anodized Silver AA25.

Guidance for specification option:

Other colours on request.

Door leaf

-

Material

Aluminium.

Glazing

-

Type

28 mm glazing.

32 mm glazing.

Manufacturer guidance

Will accept insulating glass units and infill panels 28 – 32mm thick.

Beading

-

Type

Internal.

Finish

-

Coating

Powder coating to BS EN 12206-1:2004.

Anodizing to BS 3987:1991.

Guidance for specification option:

Natural anodized finish AA25.

U-value

1.6 W/m²K.

Watertightness

100 pa.

Air permeability

300 pa.

Wind resistance

1200 pa.

Jointing

Mechanical.

Weight

100 kg.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

4.0 kg CO₂ eq/kg

Self declared

Recyclability

Aluminium building products are collected and recycled at end-of-life very efficiently, and the end-of-life recycling rate for aluminium is >90%.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

79 %
