Knauf Corridor 400 - Acoustic Ceiling Plank System

Name: Knauf Corridor 400 - Acoustic Ceiling Plank System
Brand: Knauf UK
SKU: fXUmydP2V6gzvfEpuAZxqJ

Verified by manufacturer 2 days ago

Plain

Exceptionally fast and easy installation with the self-supporting Knauf Corridor 400, with easy access to services, and ideal for corridors and narrow rooms.

Jump to:

BOS

0800 521 050 Website

Application

Suitable for use in corridors and narrow rooms.

Description

Exceptionally fast and easy installation with the self-supporting Knauf Corridor 400, with easy access to services, and ideal for corridors and narrow rooms.

Features and benefits:

Self-supporting ceiling.
Free span of up to 2.4 metres.
No suspension grid required, just a flex runner for rigidity.
Can be used in corridors over 2.4 metres by using a T35 main runner.

General information

Color	White
Finish	Painted
Material	Gypsum Guidance for specification option: Glass fibre reinforced.
Shape	Other Guidance for specification option: System. Rectangle Guidance for specification option: Planks.
Length	Bespoke Guidance for specification option: System. 1200 mm Guidance for specification option: Planks. 1800 mm Guidance for specification option: Planks. 2400 mm Guidance for specification option: Planks.
Width	400 mm Guidance for specification option: Planks. Bespoke Guidance for specification option: System.
Height	9.5 mm Guidance for specification option: Planks. Bespoke Guidance for specification option: System.

Uniclass	Ss_30_25_22_51 Modular suspended ceiling systemsPrimary
CAWS	K40/10 Unit/ modular suspended ceilings K40/115 Unit/ modular suspended ceiling system K40/135 Board-suspended ceiling system K40/265 Infill units

Product range	Danoline

Specification data - Modular suspended ceiling systems

Classification data
System performance	Acoustic performance.
System manufacturer	Knauf UK.
Ceiling support	Flex Runner. Guidance for specification option: A metal component essential for the installation of the Corridor 400 acoustic ceiling system to slot the planks into place. Length to suit plank(s) specified - see Ceiling units. Width: 65 mm. Height: 44 mm.
Support fasteners	As schedule. Guidance for specification option: Insert requirements to suit substrate.
Ceiling units	Glass fibre reinforced gypsum planks, 1200 x 400 x 9.5 mm. Glass fibre reinforced gypsum planks, 1800 x 400 x 9.5 mm. Glass fibre reinforced gypsum planks, 2400 x 400 x 9.5 mm. Manufacturer guidance Length x width x thickness.
Samples required	Not required. Required. Guidance for specification option: Insert requirements; contact manufacturer for more information.
Perimeter trims	Guidance for specification option: Consult manufacturer for options and insert requirements.
Applied finish	Tiles: white acrylic paint, RAL 9003, gloss 5.
Surface pattern	Plain.
Edge profile	D.
Weight	11.7–12.7 kg/m².
Sound absorption class	Manufacturer's standard. Guidance for specification option: Consult manufacturer for details.
Reaction to fire	A2-s1, d0.
Fire performance	N/A.
Light reflectance	Manufacturer's standard. Guidance for specification option: Depending on perforation design in accordance with DIN 5036.

Sustainability data

Country of material origin	Denmark
Country of product manufacture	Denmark
Material	Gypsum Guidance for specification option: Glass fibre reinforced.
Recyclability	Fully recyclable when separated from other waste and disposed of correctly.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	40 % Guidance for specification option: Pre-consumer recycled content: 12%. Post-consumer recycled content: 28%.
