Leicester Red Stock

Verified by manufacturer 4 months ago

Ibstock Brick Ltd

Sand faced facing brick.

Jump to:
BOS
+44 (0)1530 261999 Website

Description

Red, 2.2 kg, sand faced, clay facing bricks.


Features and benefits:

  • Manufactured in Leicester.
  • Single frog configuration.
  • Banded (plastic) and stretch-wrapped packaging.
  • Manufactured to BS EN77-1.

General information

Color

Red

Finish

Sanded

Material

Clay

Shape

Rectangle

Length

215 mm

Width

102 mm

Height

65 mm

Uniclass

Pr_20_93_52_15 Clay bricksPrimary

CAWS

F10/5 Facing brickwork

F10/110 Clay facing brickwork

Specification data - Clay bricks

Standard

To BS EN 771-1.

Brick description

Facing brick.

Work size (length x width x height)

215 x 102 x 65 mm.

Tolerances

-

Mean value

T2.

Range

R1.

Compressive strength

-

Mean compressive strength (minimum)

20 N/mm2.

Durability designation

F2 S2.

Density

-

Gross dry

1530 kg/m³.

Net dry

1740 kg/m³.

Tolerance

T2, R1.

Water absorption

19%.

Configuration

Frogged.

Thermal conductivity

0.8 K.

Water vapour permeability

5/10 µ.

Bond strength

0.15 N/mm².

Reaction to fire

Class A1 to BS EN 13501-1.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1
