Lusso Silenzio Door - Aluminium Framed Glass Door
Verified by manufacturer 2 months ago
Acoustic laminate glazing
Acoustic laminate glazing
An aluminium framed glass door with minimal perimeter framing sections.
Application
For use in a range of applications and sectors. These include commercial, education, healthcare, leisure, automotive, retail and technology.
Description
The Silenzio door can offer added acoustics, with minimal perimeter framing sections capable of being single or double-glazed and powder-coated to match Lusso's partition ranges.
Features and benefits:
- Minimalistic powder-coated aluminium framework, in a variety of RAL colours and finishes.
- A range of door options such as single, double, or unequal leaves.
- High acoustic performance ranging from 31 dB–41 dB.
- Can incorporate a variety of ironmongery ranges, including access control.
General information
Color | Other Guidance for specification option: RAL polyester powder-coated or anodized. |
Finish | Powder-coated Polished Anodized |
Material | Glass Aluminium |
Shape | Other Guidance for specification option: Bespoke. |
Length | Bespoke Guidance for specification option: Please consult manufacturer for further details. |
Width | Bespoke Guidance for specification option: Please consult manufacturer for further details. |
Height | Bespoke Guidance for specification option: Please consult manufacturer for further details. |
Warranty description | Manufacturer guidanceBased on a job specific basis, please contact Lusso for further information. |
Uniclass | |
CAWS | L20/480 Doorsets L20/55 Doorsets |
Specification data - Aluminium doorsets
Third-party certification | Constructionline-Gold; Builders Profile; CHAS; FIRAS; SMAS; Acclaim (SIPP). |
Configuration | Single leaf, single action.Double leaf, single action.Unequal leaves, single action. |
Doorset size | Manufacturer guidanceAvailable up to 3000 mm in height. Maximum leaf width 1000 mm. Consult manufacturer for details and insert requirements, or refer to a drawing. |
Performance | |
Acoustic performance | 36 dB (Rw) (12.8 mm).41 dB (Rw) (16.8 mm). |
Frame | |
Material | Lusso 25 aluminium door frame.Lusso 55 aluminium door frame.Lusso 105 aluminium door frame. |
Finish | |
Coating | Powder-coated.Anodized. |
Colour | Manufacturer guidanceInsert requirements. |
Installation fasteners | To manufacturer’s specifications. |
Door leaf | |
Material | Glass and aluminium. |
Glazing | |
Type | Clear acoustic laminate. |
Manifestation | None.2 rows of 50 mm opal frost dots.2 rows of 50 mm opal frost squares.Privacy mirror film.Client specific custom designs.Guidance for specification option: Insert requirements. |
Hardware | Hinges.Free swing pivots.Floor springs.Manufacturer guidanceInsert requirement for specified ironmongery options. |
Locking | Deadlock. Latch. Lever lock. |
Trims | 25 mm Geometric trims bonded to glazing to create mullion and/or transom effect. |
Cable management and outlets | Not required. Double glazed Tech Panel to accommodate access control and other electronics. |
Manifestation | 2 rows of 50 mm opal frost dots. 2 rows of 50 mm opal frost squares. Privacy mirror film. Client specific custom designs. Guidance for specification option: Insert requirements. |
Samples required | Manufacturer guidanceAvailable from manufacturer on request. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | 100% (Aluminium and glass) |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 80 % Manufacturer guidanceGlass % available from manufacturer on request. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
